HarmonyOS 新手入门：ArkData 向量数据库，它不是 RDB 的替代品

上一篇跑通了最小闭环：保存向量字段，再用 SQL 距离排序找回来。

这一篇接着讲一个更实际的问题：用了向量数据库，不代表所有查询都要变成“相似度”。分类、状态、时间、租户、权限这些确定条件，仍然应该交给 RDB。

先说结论

向量检索负责“谁更像”，RDB 条件负责“哪些记录有资格参与比较”。

真实业务里，通常不是全库做相似度排序，而是先用分类、状态、权限、时间范围缩小候选集，再在候选记录里做向量召回。

这个 Demo 做什么

页面保存案例时同时写入：

• category_name：普通 RDB 字段，用来做精确过滤。
• repr floatvector(2)：向量字段，用来做距离排序。

查询时分两种：

-- 不限分类
ORDER BY repr <=> ? LIMIT ?

-- 指定分类
WHERE category_name = ? ORDER BY repr <=> ? LIMIT ?

这就是“先缩小候选集，再做相似召回”的入门模型。

它怎么用

官方文档说明：floatvector 保存向量数据，<=> 是余弦距离，<-> 是 L2 距离；向量索引命中要求查询是 ORDER BY + LIMIT，并且查询距离度量和创建索引时的度量一致。

所以这个 Demo 创建了：

CREATE INDEX IF NOT EXISTS hybrid_vector_idx
ON hybrid_cases_v2 USING GSDISKANN(repr COSINE)

查询也使用 repr <=> ?，保持 COSINE 语义一致。

容易踩坑的地方

用户权限、业务状态、时间范围、分类这些条件，应该优先变成普通 SQL 条件。向量检索负责排序“候选记录里哪条最像”。这样结果更稳定，也更容易解释和调试。

这个 Demo 依赖 API 18+ 的向量数据库能力。除了设备要支持，项目的 compatibleSdkVersion 也要使用 API 18 或更高版本；否则建 floatvector 表时可能直接返回 801 Capability not support。

另外，打开数据库时不能是只读模式。这里会显式设置 isReadOnly: false，避免只读配置让 CREATE TABLE、插入和更新直接失败。

欢迎评论区一起分享～

你们做相似检索时，哪些条件必须先用 RDB 过滤？分类、权限、租户、状态，还是时间范围？如果遇到过“全库向量检索结果不稳定”的问题，也可以把场景发出来。

完整示例代码

文件位置：ArkDataVectorRdbHybridDemo.ets

这里也要分清楚：RDB + 向量检索解决的是“怎么存、怎么过滤、怎么按距离排序”，不负责把文本自动变成模型向量。官方“应用数据向量化 / Embedding”能力属于另一层 API，它的 2in1 等设备形态约束需要单独判断。

因此这个 Demo 继续使用二维教学向量，不调用 @ohos.data.intelligence。如果真实业务要接模型向量，先确认 Embedding API 在目标设备上可用，再把 floatvector(2) 改成模型输出维度。

import { common } from '@kit.AbilityKit';
import { relationalStore } from '@kit.ArkData';
import { promptAction, router } from '@kit.ArkUI';
import { BusinessError } from '@kit.BasicServicesKit';

const DB_NAME: string = 'vector_rdb_hybrid_demo.db';
const TABLE_CASE: string = 'hybrid_cases_v2';
const VECTOR_INDEX: string = 'hybrid_vector_idx';
const VECTOR_DIMENSION: number = 2;
const RESULT_LIMIT: number = 8;
const ERROR_CAPABILITY_NOT_SUPPORTED: number = 801;
const VECTOR_SOURCE_TEXT: string = '二维教学向量，不调用官方 Embedding';
const EMBEDDING_SCOPE_TEXT: string = 'Embedding 设备形态限制需单独判断';
const VECTOR_TABLE_UNAVAILABLE_TIP: string =
  'isVectorSupported 返回支持，但 CREATE TABLE floatvector 返回 801。当前 Demo 已显式设置 isReadOnly=false；Demo 使用二维教学向量，不调用官方 Embedding。若仍失败，请继续检查系统镜像或真机向量数据库能力。';

class HybridCaseItem {
  id: number = 0;
  title: string = '';
  categoryName: string = '';
  content: string = '';
  distance: number = 0;
  vectorText: string = '';
  createdAt: string = '';

  constructor(
    id: number,
    title: string,
    categoryName: string,
    content: string,
    distance: number,
    vectorText: string,
    createdAt: string
  ) {
    this.id = id;
    this.title = title;
    this.categoryName = categoryName;
    this.content = content;
    this.distance = distance;
    this.vectorText = vectorText;
    this.createdAt = createdAt;
  }
}

class HybridInfoItem {
  label: string = '';
  value: string = '';

  constructor(label: string, value: string) {
    this.label = label;
    this.value = value;
  }
}

@Entry
@Component
struct ArkDataVectorRdbHybridDemo {
  @State caseTitle: string = '首选项保存主题';
  @State caseContent: string = '用户主题、字号、引导页状态这类轻量配置，优先用 Preferences 保存。';
  @State caseCategory: string = 'ArkData';
  @State searchCategory: string = '全部';
  @State queryText: string = '主题模式应该怎么保存';
  @State tips: string = '先用 RDB 分类过滤，再让向量数据库对候选记录做距离排序。';
  @State items: HybridCaseItem[] = [];
  @State infoItems: HybridInfoItem[] = [];
  @State showResultSheet: boolean = false;
  @State vectorSupportedText: string = '待检测';
  @State stageText: string = '等待初始化';
  @State indexStatusText: string = '尚未创建';

  private store: relationalStore.RdbStore | undefined = undefined;
  private categories: string[] = ['ArkData', 'ArkUI', 'AI'];
  private searchCategories: string[] = ['全部', 'ArkData', 'ArkUI', 'AI'];

  aboutToAppear(): void {
    this.vectorSupportedText = relationalStore.isVectorSupported() ? '支持' : '不支持';
    if (relationalStore.isVectorSupported()) {
      this.loadCases();
    } else {
      this.items = [];
      this.tips = '当前设备不支持向量数据库，页面可查看组合检索流程。';
      this.updateInfoItems('设备不支持向量能力', 0);
    }
  }

  private errorToText(err: BusinessError): string {
    return `code=${err.code}, message=${err.message}`;
  }

  private isCapabilityNotSupported(err: BusinessError): boolean {
    return err.code === ERROR_CAPABILITY_NOT_SUPPORTED;
  }

  private markVectorTableUnavailable(action: string): void {
    this.items = [];
    this.vectorSupportedText = '建表不支持(801)';
    this.indexStatusText = '未创建';
    this.tips = VECTOR_TABLE_UNAVAILABLE_TIP;
    this.updateInfoItems(action, 0);
  }

  private async getStore(): Promise<relationalStore.RdbStore> {
    if (this.store !== undefined) {
      return this.store;
    }

    if (!relationalStore.isVectorSupported()) {
      throw new Error('Vector store is not supported on this device');
    }

    const context = getContext(this) as common.UIAbilityContext;
    const config: relationalStore.StoreConfig = {
      name: DB_NAME,
      securityLevel: relationalStore.SecurityLevel.S1,
      vector: true,
      isReadOnly: false
    };
    this.stageText = '正在打开向量 RDB';
    const store = await relationalStore.getRdbStore(context, config);
    this.stageText = '正在创建组合检索表';
    await store.executeSql(
      `CREATE TABLE IF NOT EXISTS ${TABLE_CASE} (` +
        'id INTEGER PRIMARY KEY AUTOINCREMENT, ' +
        'title TEXT NOT NULL, ' +
        'category_name TEXT NOT NULL, ' +
        'content TEXT NOT NULL, ' +
        `repr floatvector(${VECTOR_DIMENSION}) NOT NULL, ` +
        'created_at TEXT NOT NULL)'
    );
    await this.prepareVectorIndex(store);
    this.store = store;
    return store;
  }

  private async prepareVectorIndex(store: relationalStore.RdbStore): Promise<void> {
    try {
      this.stageText = '正在创建向量索引';
      await store.executeSql(
        `CREATE INDEX IF NOT EXISTS ${VECTOR_INDEX} ON ${TABLE_CASE} USING GSDISKANN(repr COSINE)`
      );
      this.indexStatusText = '已创建';
    } catch (err) {
      const error = err as BusinessError;
      this.indexStatusText = '创建失败，已降级为无索引向量查询';
      console.error(`Hybrid vector index create failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  private createTeachingVector(text: string): Float32Array {
    const source = text.length > 0 ? text : '空文本';
    let dataScore = 0;
    let uiScore = 0;
    for (let index = 0; index < source.length; index++) {
      const char = source.charAt(index);
      const code = source.charCodeAt(index);
      if (char === 'D' || char === 'd' || char === '数' || char === '存' || char === '库') {
        dataScore += 2;
      } else if (char === 'U' || char === 'u' || char === '界' || char === '面' || char === '视') {
        uiScore += 2;
      } else if (code % 2 === 0) {
        dataScore += 1;
      } else {
        uiScore += 1;
      }
    }
    const total = Math.max(1, dataScore + uiScore);
    return Float32Array.from([dataScore / total, uiScore / total]);
  }

  private vectorToText(vector: Float32Array): string {
    if (vector.length < VECTOR_DIMENSION) {
      return '[]';
    }
    return `[${vector[0].toFixed(3)}, ${vector[1].toFixed(3)}]`;
  }

  private readVector(value: relationalStore.ValueType): Float32Array {
    if (value instanceof Float32Array) {
      return value;
    }
    return new Float32Array(0);
  }

  private updateInfoItems(action: string, filteredCount: number): void {
    this.infoItems = [
      new HybridInfoItem('数据库名称', DB_NAME),
      new HybridInfoItem('表名', TABLE_CASE),
      new HybridInfoItem('普通字段', 'title / category_name / content / created_at'),
      new HybridInfoItem('向量字段', `repr floatvector(${VECTOR_DIMENSION})`),
      new HybridInfoItem('向量索引', `${VECTOR_INDEX} / GSDISKANN / COSINE / ${this.indexStatusText}`),
      new HybridInfoItem('向量来源', VECTOR_SOURCE_TEXT),
      new HybridInfoItem('Embedding', EMBEDDING_SCOPE_TEXT),
      new HybridInfoItem('只读模式', 'false'),
      new HybridInfoItem('向量能力', this.vectorSupportedText),
      new HybridInfoItem('初始化阶段', this.stageText),
      new HybridInfoItem('RDB 分类条件', this.searchCategory),
      new HybridInfoItem('当前结果数', `${filteredCount}`),
      new HybridInfoItem('最近动作', action)
    ];
  }

  private readRows(resultSet: relationalStore.ResultSet, hasDistance: boolean): HybridCaseItem[] {
    const rows: HybridCaseItem[] = [];
    const idIndex = resultSet.getColumnIndex('id');
    const titleIndex = resultSet.getColumnIndex('title');
    const categoryIndex = resultSet.getColumnIndex('category_name');
    const contentIndex = resultSet.getColumnIndex('content');
    const vectorIndex = resultSet.getColumnIndex('repr');
    const createdAtIndex = resultSet.getColumnIndex('created_at');
    const distanceIndex = hasDistance ? resultSet.getColumnIndex('distance') : -1;
    while (resultSet.goToNextRow()) {
      const vector = this.readVector(resultSet.getValue(vectorIndex));
      const distance = hasDistance ? resultSet.getDouble(distanceIndex) : 0;
      rows.push(new HybridCaseItem(
        resultSet.getLong(idIndex),
        resultSet.getString(titleIndex),
        resultSet.getString(categoryIndex),
        resultSet.getString(contentIndex),
        distance,
        this.vectorToText(vector),
        resultSet.getString(createdAtIndex)
      ));
    }
    return rows;
  }

  private async loadCases(action: string = '读取全部案例'): Promise<void> {
    let resultSet: relationalStore.ResultSet | undefined = undefined;
    if (!relationalStore.isVectorSupported()) {
      this.items = [];
      this.vectorSupportedText = '不支持';
      this.tips = '当前设备不支持向量数据库，无法创建 floatvector 表。';
      this.updateInfoItems('设备不支持向量能力', 0);
      return;
    }

    try {
      const store = await this.getStore();
      this.stageText = '正在读取组合检索表';
      resultSet = await store.querySql(
        `SELECT id, title, category_name, content, repr, created_at FROM ${TABLE_CASE} ORDER BY id DESC`
      );
      this.items = this.readRows(resultSet, false);
      this.stageText = '读取完成';
      this.updateInfoItems(action, this.items.length);
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('向量表不可用');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Hybrid vector load failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `读取失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      this.items = [];
      this.updateInfoItems('读取失败', 0);
      promptAction.showToast({ message: '读取失败' });
      console.error(`Hybrid vector load failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    } finally {
      if (resultSet !== undefined) {
        resultSet.close();
      }
    }
  }

  private async saveCase(): Promise<void> {
    try {
      if (!relationalStore.isVectorSupported()) {
        this.tips = '当前设备不支持向量数据库，无法保存向量字段。';
        this.updateInfoItems('保存被跳过', this.items.length);
        promptAction.showToast({ message: '设备不支持向量能力' });
        return;
      }

      const store = await this.getStore();
      const title = this.caseTitle.length > 0 ? this.caseTitle : '未命名案例';
      const content = this.caseContent.length > 0 ? this.caseContent : '空内容';
      const vector = this.createTeachingVector(`${this.caseCategory}\n${title}\n${content}`);
      const values: relationalStore.ValuesBucket = {
        title: title,
        category_name: this.caseCategory,
        content: content,
        repr: vector,
        created_at: new Date().toString()
      };
      await store.insert(TABLE_CASE, values);
      await this.loadCases('保存案例');
      this.tips = `保存成功：${this.caseCategory} 案例已写入向量字段 ${this.vectorToText(vector)}。`;
      promptAction.showToast({ message: '案例已保存' });
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('保存被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Hybrid vector save failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `保存失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '保存失败' });
      console.error(`Hybrid vector save failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  private async searchCases(): Promise<void> {
    let resultSet: relationalStore.ResultSet | undefined = undefined;
    if (!relationalStore.isVectorSupported()) {
      this.tips = '当前设备不支持向量数据库，无法执行向量距离检索。';
      this.updateInfoItems('检索被跳过', this.items.length);
      promptAction.showToast({ message: '设备不支持向量能力' });
      return;
    }

    try {
      const store = await this.getStore();
      const queryVector = this.createTeachingVector(this.queryText);
      this.stageText = '正在执行组合向量检索';
      if (this.searchCategory === '全部') {
        resultSet = await store.querySql(
          `SELECT id, title, category_name, content, repr, created_at, repr <=> ? AS distance FROM ${TABLE_CASE} ` +
            'ORDER BY repr <=> ? LIMIT ?',
          [queryVector, queryVector, RESULT_LIMIT]
        );
      } else {
        resultSet = await store.querySql(
          `SELECT id, title, category_name, content, repr, created_at, repr <=> ? AS distance FROM ${TABLE_CASE} ` +
            'WHERE category_name = ? ORDER BY repr <=> ? LIMIT ?',
          [queryVector, this.searchCategory, queryVector, RESULT_LIMIT]
        );
      }
      this.items = this.readRows(resultSet, true);
      this.stageText = '检索完成';
      this.updateInfoItems('RDB 过滤后向量检索', this.items.length);
      this.tips = `检索完成：分类=${this.searchCategory}，查询向量 ${this.vectorToText(queryVector)}。`;
      this.showResultSheet = true;
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('检索被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Hybrid vector search failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `检索失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '检索失败' });
      console.error(`Hybrid vector search failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    } finally {
      if (resultSet !== undefined) {
        resultSet.close();
      }
    }
  }

  private async clearCases(): Promise<void> {
    try {
      if (!relationalStore.isVectorSupported()) {
        this.items = [];
        this.tips = '当前设备不支持向量数据库，没有可清空的向量表。';
        this.updateInfoItems('清空被跳过', 0);
        return;
      }

      const store = await this.getStore();
      await store.executeSql(`DELETE FROM ${TABLE_CASE}`);
      await this.loadCases('清空表数据');
      this.tips = '数据已清空。';
      promptAction.showToast({ message: '已清空' });
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('清空被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Hybrid vector clear failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `清空失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '清空失败' });
      console.error(`Hybrid vector clear failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  private async showHybridInfo(): Promise<void> {
    await this.loadCases('查看组合检索信息');
    this.showResultSheet = true;
  }

  @Builder
  private categoryButtons() {
    Row({ space: 8 }) {
      ForEach(this.categories, (categoryName: string) => {
        Button(categoryName)
          .layoutWeight(1)
          .height(38)
          .fontSize(13)
          .fontColor(this.caseCategory === categoryName ? '#FFFFFF' : '#0F172A')
          .backgroundColor(this.caseCategory === categoryName ? '#0F766E' : '#CCFBF1')
          .onClick(() => {
            this.caseCategory = categoryName;
          })
      }, (categoryName: string) => categoryName)
    }
    .width('100%')
  }

  @Builder
  private searchCategoryButtons() {
    Row({ space: 8 }) {
      ForEach(this.searchCategories, (categoryName: string) => {
        Button(categoryName)
          .layoutWeight(1)
          .height(38)
          .fontSize(12)
          .fontColor(this.searchCategory === categoryName ? '#FFFFFF' : '#0F172A')
          .backgroundColor(this.searchCategory === categoryName ? '#155E75' : '#CFFAFE')
          .onClick(() => {
            this.searchCategory = categoryName;
          })
      }, (categoryName: string) => categoryName)
    }
    .width('100%')
  }

  @Builder
  private hybridInfoSheet() {
    Column({ space: 14 }) {
      Text('RDB + 向量检索信息')
        .width('100%')
        .fontSize(22)
        .fontWeight(700)
        .fontColor('#0F172A')

      Text('分类交给 RDB，语义距离交给向量数据库；查询保持 ORDER BY + LIMIT。')
        .width('100%')
        .fontSize(13)
        .fontColor('#64748B')

      Column({ space: 8 }) {
        ForEach(this.infoItems, (item: HybridInfoItem) => {
          Column({ space: 4 }) {
            Text(item.label)
              .fontSize(12)
              .fontColor('#64748B')
            Text(item.value)
              .fontSize(16)
              .fontColor('#0F172A')
          }
          .width('100%')
          .padding(12)
          .backgroundColor('#F8FAFC')
          .borderRadius(8)
        }, (item: HybridInfoItem) => item.label)
      }
      .width('100%')

      Button('关闭')
        .width('100%')
        .height(44)
        .fontSize(16)
        .backgroundColor('#0F766E')
        .onClick(() => {
          this.showResultSheet = false;
        })
    }
    .width('100%')
    .padding({ left: 20, right: 20, top: 12, bottom: 20 })
  }

  build() {
    Scroll() {
      Column({ space: 18 }) {
        Row() {
          Text('返回')
            .fontSize(14)
            .fontColor('#0F766E')
            .onClick(() => {
              router.back();
            })
          Blank()
        }
        .width('100%')

        Text('RDB + 向量检索')
          .width('100%')
          .fontSize(28)
          .fontWeight(700)
          .fontColor('#182431')

        Text('分类、状态、时间这类精确条件交给 RDB；意思像不像交给向量距离。')
          .width('100%')
          .fontSize(14)
          .fontColor('#56616F')

        Text(`当前向量能力：${this.vectorSupportedText}`)
          .width('100%')
          .fontSize(13)
          .fontColor(this.vectorSupportedText === '支持' ? '#0F766E' : '#B45309')

        this.categoryButtons()

        TextInput({ placeholder: '案例标题', text: this.caseTitle })
          .height(44)
          .fontSize(16)
          .backgroundColor('#F0FDFA')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.caseTitle = value;
          })

        TextArea({ placeholder: '案例内容', text: this.caseContent })
          .height(92)
          .fontSize(15)
          .backgroundColor('#F0FDFA')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.caseContent = value;
          })

        Text('检索分类')
          .width('100%')
          .fontSize(13)
          .fontColor('#64748B')

        this.searchCategoryButtons()

        TextInput({ placeholder: '输入检索问题', text: this.queryText })
          .height(44)
          .fontSize(16)
          .backgroundColor('#ECFEFF')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.queryText = value;
          })

        Row({ space: 10 }) {
          Button('保存')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .backgroundColor('#0F766E')
            .onClick(() => {
              this.saveCase();
            })
          Button('过滤检索')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#99F6E4')
            .onClick(() => {
              this.searchCases();
            })
          Button('查看')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#CFFAFE')
            .onClick(() => {
              this.showHybridInfo();
            })
          Button('清空')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#CBD5E1')
            .onClick(() => {
              this.clearCases();
            })
        }
        .width('100%')

        Column({ space: 8 }) {
          ForEach(this.items, (item: HybridCaseItem) => {
            Column({ space: 5 }) {
              Row() {
                Text(item.title)
                  .fontSize(17)
                  .fontWeight(700)
                  .fontColor('#0F172A')
                  .layoutWeight(1)
                Text(item.categoryName)
                  .fontSize(12)
                  .fontColor('#0F766E')
              }
              .width('100%')
              Text(item.content)
                .width('100%')
                .fontSize(13)
                .fontColor('#334155')
              Text(`distance=${item.distance.toFixed(4)} | vector=${item.vectorText} | id=${item.id}`)
                .width('100%')
                .fontSize(12)
                .fontColor('#64748B')
              Text(item.createdAt)
                .width('100%')
                .fontSize(12)
                .fontColor('#94A3B8')
            }
            .width('100%')
            .padding(14)
            .backgroundColor('#F8FAFC')
            .borderRadius(8)
          }, (item: HybridCaseItem) => `${item.id}`)
        }
        .width('100%')

        Text(this.tips)
          .width('100%')
          .fontSize(13)
          .fontColor('#64748B')
      }
      .width('100%')
      .padding(24)
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#FFFFFF')
    .bindSheet(this.showResultSheet, this.hybridInfoSheet(), {
      height: SheetSize.MEDIUM,
      dragBar: true,
      showClose: true,
      onDisappear: () => {
        this.showResultSheet = false;
      }
    })
  }
}
