HarmonyOS 新手入门：ArkData 向量数据库，做一个本地知识库

前两篇分别讲了最小闭环和 RDB 混合过滤。第三篇把它落到一个常见 AI 应用场景：本地知识库。

先说结论

本地知识库不是把整篇文章直接塞进一个向量字段。

更常见的做法是：先把长文本切成片段，再给每个片段生成向量。检索时先找相似片段，后续再把片段交给摘要、问答或生成模块。

这个 Demo 做什么

页面把一段长文本切成多个 chunk，每个 chunk 单独写入 RDB 表：

• source_title 保存资料标题。
• chunk_text 保存片段正文。
• repr floatvector(2) 保存片段向量。
• created_at 保存写入时间。

检索时把问题也转成二维教学向量，然后用官方文档里的余弦距离写法召回：

SELECT id, source_title, chunk_text, repr, created_at, repr <=> ? AS distance
FROM kb_chunks_v2
ORDER BY repr <=> ?
LIMIT ?

为什么要切片

知识库通常不是整篇文章直接入库。更常见的做法是先切成较短片段，再分别向量化。这样检索结果可以直接定位到具体片段，后续也更容易把片段交给摘要、问答或生成模块。

它怎么用

这篇继续遵循官方向量数据库文档的核心约束：打开数据库时启用 vector: true，表字段使用 floatvector(N)，索引使用 GSDISKANN，查询使用 ORDER BY + LIMIT。

Demo 使用二维教学向量是为了让新手能看到完整数据流。真实项目替换为模型向量时，需要把 floatvector(2) 改成模型输出维度，并保证写入的 Float32Array 长度一致。

如果页面显示 建表不支持(801)，优先检查两件事：运行环境是否真支持向量数据库，以及项目 compatibleSdkVersion 是否已经升到 API 18+。只看 isVectorSupported() 不够，最终还要以 CREATE TABLE ... floatvector 是否成功为准。

还要确认数据库不是只读打开。isReadOnly: true 会让写 SQL 直接失败；这个 Demo 已经显式写成 isReadOnly: false。

欢迎评论区一起分享～

你们做知识库时会怎么切片？按字数、按段落、按标题层级，还是按业务字段？如果后续要接真实模型向量，这个切片策略会直接影响召回效果。

完整示例代码

文件位置：ArkDataVectorKnowledgeBaseDemo.ets

知识库 Demo 也不要误会成“手机端一定可以直接调用官方文本转向量”。这里的向量来自页面里的二维教学算法，只是为了把切片、入库、召回这条链路跑通。

官方“应用数据向量化 / Embedding”是单独的模型能力，文档里的 2in1 等设备形态约束需要单独看。真实项目要做本地知识库，先确认目标设备能不能生成模型向量，再决定是端侧 Embedding、云侧生成，还是用其它模型服务生成后写入 floatvector(N)。

import { common } from '@kit.AbilityKit';
import { relationalStore } from '@kit.ArkData';
import { promptAction, router } from '@kit.ArkUI';
import { BusinessError } from '@kit.BasicServicesKit';

const DB_NAME: string = 'vector_knowledge_base_demo.db';
const TABLE_CHUNK: string = 'kb_chunks_v2';
const VECTOR_INDEX: string = 'kb_chunk_vector_idx';
const VECTOR_DIMENSION: number = 2;
const RESULT_LIMIT: number = 8;
const CHUNK_SIZE: number = 42;
const ERROR_CAPABILITY_NOT_SUPPORTED: number = 801;
const VECTOR_SOURCE_TEXT: string = '二维教学向量，不调用官方 Embedding';
const EMBEDDING_SCOPE_TEXT: string = 'Embedding 设备形态限制需单独判断';
const VECTOR_TABLE_UNAVAILABLE_TIP: string =
  'isVectorSupported 返回支持，但 CREATE TABLE floatvector 返回 801。当前 Demo 已显式设置 isReadOnly=false；Demo 使用二维教学向量，不调用官方 Embedding。若仍失败，请继续检查系统镜像或真机向量数据库能力。';

class KnowledgeChunkItem {
  id: number = 0;
  sourceTitle: string = '';
  chunkText: string = '';
  distance: number = 0;
  vectorText: string = '';
  createdAt: string = '';

  constructor(
    id: number,
    sourceTitle: string,
    chunkText: string,
    distance: number,
    vectorText: string,
    createdAt: string
  ) {
    this.id = id;
    this.sourceTitle = sourceTitle;
    this.chunkText = chunkText;
    this.distance = distance;
    this.vectorText = vectorText;
    this.createdAt = createdAt;
  }
}

class KnowledgeInfoItem {
  label: string = '';
  value: string = '';

  constructor(label: string, value: string) {
    this.label = label;
    this.value = value;
  }
}

@Entry
@Component
struct ArkDataVectorKnowledgeBaseDemo {
  @State sourceTitle: string = 'ArkData 本地知识';
  @State sourceText: string = 'Preferences 适合保存轻量配置。RDB 适合保存结构化业务数据。向量数据库适合保存向量化结果，并用距离排序找相似内容。';
  @State queryText: string = '怎么找相似知识片段';
  @State tips: string = '把一段资料切成多个 chunk，分别写入向量数据库，再按距离召回。';
  @State items: KnowledgeChunkItem[] = [];
  @State infoItems: KnowledgeInfoItem[] = [];
  @State showInfoSheet: boolean = false;
  @State vectorSupportedText: string = '待检测';
  @State stageText: string = '等待初始化';
  @State indexStatusText: string = '尚未创建';

  private store: relationalStore.RdbStore | undefined = undefined;

  aboutToAppear(): void {
    this.vectorSupportedText = relationalStore.isVectorSupported() ? '支持' : '不支持';
    if (relationalStore.isVectorSupported()) {
      this.loadChunks();
    } else {
      this.items = [];
      this.tips = '当前设备不支持向量数据库，页面可查看知识库流程。';
      this.updateInfoItems('设备不支持向量能力');
    }
  }

  private errorToText(err: BusinessError): string {
    return `code=${err.code}, message=${err.message}`;
  }

  private isCapabilityNotSupported(err: BusinessError): boolean {
    return err.code === ERROR_CAPABILITY_NOT_SUPPORTED;
  }

  private markVectorTableUnavailable(action: string): void {
    this.items = [];
    this.vectorSupportedText = '建表不支持(801)';
    this.indexStatusText = '未创建';
    this.tips = VECTOR_TABLE_UNAVAILABLE_TIP;
    this.updateInfoItems(action);
  }

  private async getStore(): Promise<relationalStore.RdbStore> {
    if (this.store !== undefined) {
      return this.store;
    }

    if (!relationalStore.isVectorSupported()) {
      throw new Error('Vector store is not supported on this device');
    }

    const context = getContext(this) as common.UIAbilityContext;
    const config: relationalStore.StoreConfig = {
      name: DB_NAME,
      securityLevel: relationalStore.SecurityLevel.S1,
      vector: true,
      isReadOnly: false
    };
    this.stageText = '正在打开向量 RDB';
    const store = await relationalStore.getRdbStore(context, config);
    this.stageText = '正在创建知识片段表';
    await store.executeSql(
      `CREATE TABLE IF NOT EXISTS ${TABLE_CHUNK} (` +
        'id INTEGER PRIMARY KEY AUTOINCREMENT, ' +
        'source_title TEXT NOT NULL, ' +
        'chunk_text TEXT NOT NULL, ' +
        `repr floatvector(${VECTOR_DIMENSION}) NOT NULL, ` +
        'created_at TEXT NOT NULL)'
    );
    await this.prepareVectorIndex(store);
    this.store = store;
    return store;
  }

  private async prepareVectorIndex(store: relationalStore.RdbStore): Promise<void> {
    try {
      this.stageText = '正在创建向量索引';
      await store.executeSql(
        `CREATE INDEX IF NOT EXISTS ${VECTOR_INDEX} ON ${TABLE_CHUNK} USING GSDISKANN(repr COSINE)`
      );
      this.indexStatusText = '已创建';
    } catch (err) {
      const error = err as BusinessError;
      this.indexStatusText = '创建失败，已降级为无索引向量查询';
      console.error(`Knowledge vector index create failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  private splitToChunks(text: string): string[] {
    const source = text.replace(/\n/g, ' ').trim();
    const chunks: string[] = [];
    let start = 0;
    while (start < source.length) {
      const end = Math.min(source.length, start + CHUNK_SIZE);
      const chunk = source.substring(start, end).trim();
      if (chunk.length > 0) {
        chunks.push(chunk);
      }
      start = end;
    }
    return chunks;
  }

  private createTeachingVector(text: string): Float32Array {
    const source = text.length > 0 ? text : '空文本';
    let conceptScore = 0;
    let actionScore = 0;
    for (let index = 0; index < source.length; index++) {
      const char = source.charAt(index);
      const code = source.charCodeAt(index);
      if (char === '库' || char === '数' || char === '向' || char === '量' || char === 'R') {
        conceptScore += 2;
      } else if (char === '保' || char === '查' || char === '找' || char === '写' || char === '用') {
        actionScore += 2;
      } else if (code % 2 === 0) {
        conceptScore += 1;
      } else {
        actionScore += 1;
      }
    }
    const total = Math.max(1, conceptScore + actionScore);
    return Float32Array.from([conceptScore / total, actionScore / total]);
  }

  private vectorToText(vector: Float32Array): string {
    if (vector.length < VECTOR_DIMENSION) {
      return '[]';
    }
    return `[${vector[0].toFixed(3)}, ${vector[1].toFixed(3)}]`;
  }

  private readVector(value: relationalStore.ValueType): Float32Array {
    if (value instanceof Float32Array) {
      return value;
    }
    return new Float32Array(0);
  }

  private updateInfoItems(action: string): void {
    this.infoItems = [
      new KnowledgeInfoItem('数据库名称', DB_NAME),
      new KnowledgeInfoItem('表名', TABLE_CHUNK),
      new KnowledgeInfoItem('向量字段', `repr floatvector(${VECTOR_DIMENSION})`),
      new KnowledgeInfoItem('向量索引', `${VECTOR_INDEX} / GSDISKANN / COSINE / ${this.indexStatusText}`),
      new KnowledgeInfoItem('向量来源', VECTOR_SOURCE_TEXT),
      new KnowledgeInfoItem('Embedding', EMBEDDING_SCOPE_TEXT),
      new KnowledgeInfoItem('只读模式', 'false'),
      new KnowledgeInfoItem('chunk 长度', `${CHUNK_SIZE} 字符`),
      new KnowledgeInfoItem('向量能力', this.vectorSupportedText),
      new KnowledgeInfoItem('初始化阶段', this.stageText),
      new KnowledgeInfoItem('当前展示数', `${this.items.length}`),
      new KnowledgeInfoItem('最近动作', action)
    ];
  }

  private readRows(resultSet: relationalStore.ResultSet, hasDistance: boolean): KnowledgeChunkItem[] {
    const rows: KnowledgeChunkItem[] = [];
    const idIndex = resultSet.getColumnIndex('id');
    const titleIndex = resultSet.getColumnIndex('source_title');
    const chunkIndex = resultSet.getColumnIndex('chunk_text');
    const vectorIndex = resultSet.getColumnIndex('repr');
    const createdAtIndex = resultSet.getColumnIndex('created_at');
    const distanceIndex = hasDistance ? resultSet.getColumnIndex('distance') : -1;
    while (resultSet.goToNextRow()) {
      const vector = this.readVector(resultSet.getValue(vectorIndex));
      const distance = hasDistance ? resultSet.getDouble(distanceIndex) : 0;
      rows.push(new KnowledgeChunkItem(
        resultSet.getLong(idIndex),
        resultSet.getString(titleIndex),
        resultSet.getString(chunkIndex),
        distance,
        this.vectorToText(vector),
        resultSet.getString(createdAtIndex)
      ));
    }
    return rows;
  }

  private async loadChunks(action: string = '读取知识片段'): Promise<void> {
    let resultSet: relationalStore.ResultSet | undefined = undefined;
    if (!relationalStore.isVectorSupported()) {
      this.items = [];
      this.vectorSupportedText = '不支持';
      this.tips = '当前设备不支持向量数据库，无法创建 floatvector 表。';
      this.updateInfoItems('设备不支持向量能力');
      return;
    }

    try {
      const store = await this.getStore();
      this.stageText = '正在读取知识片段表';
      resultSet = await store.querySql(
        `SELECT id, source_title, chunk_text, repr, created_at FROM ${TABLE_CHUNK} ORDER BY id DESC`
      );
      this.items = this.readRows(resultSet, false);
      this.stageText = '读取完成';
      this.updateInfoItems(action);
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('向量表不可用');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Knowledge vector load failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.items = [];
      this.tips = `读取失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      this.updateInfoItems('读取失败');
      promptAction.showToast({ message: '读取失败' });
      console.error(`Knowledge vector load failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    } finally {
      if (resultSet !== undefined) {
        resultSet.close();
      }
    }
  }

  private async saveKnowledge(): Promise<void> {
    try {
      if (!relationalStore.isVectorSupported()) {
        this.tips = '当前设备不支持向量数据库，无法保存向量字段。';
        this.updateInfoItems('写入被跳过');
        promptAction.showToast({ message: '设备不支持向量能力' });
        return;
      }

      const store = await this.getStore();
      const title = this.sourceTitle.length > 0 ? this.sourceTitle : '未命名资料';
      const chunks = this.splitToChunks(this.sourceText.length > 0 ? this.sourceText : '空内容');
      const now = new Date().toString();
      for (let index = 0; index < chunks.length; index++) {
        const chunk = chunks[index];
        const vector = this.createTeachingVector(`${title}\n${chunk}`);
        const values: relationalStore.ValuesBucket = {
          source_title: title,
          chunk_text: chunk,
          repr: vector,
          created_at: now
        };
        await store.insert(TABLE_CHUNK, values);
      }
      await this.loadChunks('写入知识库');
      this.tips = `写入成功：${chunks.length} 个 chunk 已保存到向量数据库。`;
      promptAction.showToast({ message: '知识库已写入' });
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('写入被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Knowledge vector save failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `写入失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '写入失败' });
      console.error(`Knowledge vector save failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  private async searchKnowledge(): Promise<void> {
    let resultSet: relationalStore.ResultSet | undefined = undefined;
    if (!relationalStore.isVectorSupported()) {
      this.tips = '当前设备不支持向量数据库，无法执行向量距离检索。';
      this.updateInfoItems('检索被跳过');
      promptAction.showToast({ message: '设备不支持向量能力' });
      return;
    }

    try {
      const store = await this.getStore();
      const queryVector = this.createTeachingVector(this.queryText);
      this.stageText = '正在执行知识库向量检索';
      resultSet = await store.querySql(
        `SELECT id, source_title, chunk_text, repr, created_at, repr <=> ? AS distance FROM ${TABLE_CHUNK} ` +
          'ORDER BY repr <=> ? LIMIT ?',
        [queryVector, queryVector, RESULT_LIMIT]
      );
      this.items = this.readRows(resultSet, true);
      this.stageText = '检索完成';
      this.updateInfoItems('查询知识库');
      this.tips = `召回完成：查询向量 ${this.vectorToText(queryVector)}，distance 越小越接近。`;
      this.showInfoSheet = true;
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('检索被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Knowledge vector search failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `检索失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '检索失败' });
      console.error(`Knowledge vector search failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    } finally {
      if (resultSet !== undefined) {
        resultSet.close();
      }
    }
  }

  private async clearKnowledge(): Promise<void> {
    try {
      if (!relationalStore.isVectorSupported()) {
        this.items = [];
        this.tips = '当前设备不支持向量数据库，没有可清空的向量表。';
        this.updateInfoItems('清空被跳过');
        return;
      }

      const store = await this.getStore();
      await store.executeSql(`DELETE FROM ${TABLE_CHUNK}`);
      await this.loadChunks('清空知识库');
      this.tips = '知识库已清空。';
      promptAction.showToast({ message: '已清空' });
    } catch (err) {
      const error = err as BusinessError;
      if (this.isCapabilityNotSupported(error)) {
        this.markVectorTableUnavailable('清空被跳过');
        promptAction.showToast({ message: '向量表不可用' });
        console.error(`Knowledge vector clear failed: stage=${this.stageText}, ${this.errorToText(error)}`);
        return;
      }
      this.tips = `清空失败：阶段=${this.stageText}，${this.errorToText(error)}。`;
      promptAction.showToast({ message: '清空失败' });
      console.error(`Knowledge vector clear failed: stage=${this.stageText}, ${this.errorToText(error)}`);
    }
  }

  @Builder
  private infoSheet() {
    Column({ space: 14 }) {
      Text('本地知识库信息')
        .width('100%')
        .fontSize(22)
        .fontWeight(700)
        .fontColor('#0F172A')

      Text('每个 chunk 独立保存向量，查询时使用 ORDER BY repr <=> ? LIMIT。')
        .width('100%')
        .fontSize(13)
        .fontColor('#64748B')

      Column({ space: 8 }) {
        ForEach(this.infoItems, (item: KnowledgeInfoItem) => {
          Column({ space: 4 }) {
            Text(item.label)
              .fontSize(12)
              .fontColor('#64748B')
            Text(item.value)
              .fontSize(16)
              .fontColor('#0F172A')
          }
          .width('100%')
          .padding(12)
          .backgroundColor('#F8FAFC')
          .borderRadius(8)
        }, (item: KnowledgeInfoItem) => item.label)
      }
      .width('100%')

      Button('关闭')
        .width('100%')
        .height(44)
        .fontSize(16)
        .backgroundColor('#7C2D12')
        .onClick(() => {
          this.showInfoSheet = false;
        })
    }
    .width('100%')
    .padding({ left: 20, right: 20, top: 12, bottom: 20 })
  }

  build() {
    Scroll() {
      Column({ space: 18 }) {
        Row() {
          Text('返回')
            .fontSize(14)
            .fontColor('#7C2D12')
            .onClick(() => {
              router.back();
            })
          Blank()
        }
        .width('100%')

        Text('本地知识库')
          .width('100%')
          .fontSize(28)
          .fontWeight(700)
          .fontColor('#182431')

        Text('把长文本切成片段，逐条写入向量字段，再按数据库侧余弦距离召回。')
          .width('100%')
          .fontSize(14)
          .fontColor('#56616F')

        Text(`当前向量能力：${this.vectorSupportedText}`)
          .width('100%')
          .fontSize(13)
          .fontColor(this.vectorSupportedText === '支持' ? '#7C2D12' : '#B45309')

        TextInput({ placeholder: '资料标题', text: this.sourceTitle })
          .height(44)
          .fontSize(16)
          .backgroundColor('#FFF7ED')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.sourceTitle = value;
          })

        TextArea({ placeholder: '粘贴一段资料', text: this.sourceText })
          .height(120)
          .fontSize(15)
          .backgroundColor('#FFF7ED')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.sourceText = value;
          })

        TextInput({ placeholder: '输入问题', text: this.queryText })
          .height(44)
          .fontSize(16)
          .backgroundColor('#FFEDD5')
          .fontColor('#0F172A')
          .onChange((value: string) => {
            this.queryText = value;
          })

        Row({ space: 10 }) {
          Button('写入')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .backgroundColor('#7C2D12')
            .onClick(() => {
              this.saveKnowledge();
            })
          Button('检索')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#FED7AA')
            .onClick(() => {
              this.searchKnowledge();
            })
          Button('查看')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#FFEDD5')
            .onClick(() => {
              this.loadChunks('查看知识库');
              this.showInfoSheet = true;
            })
          Button('清空')
            .layoutWeight(1)
            .height(44)
            .fontSize(15)
            .fontColor('#0F172A')
            .backgroundColor('#CBD5E1')
            .onClick(() => {
              this.clearKnowledge();
            })
        }
        .width('100%')

        Column({ space: 8 }) {
          ForEach(this.items, (item: KnowledgeChunkItem) => {
            Column({ space: 5 }) {
              Text(item.sourceTitle)
                .width('100%')
                .fontSize(17)
                .fontWeight(700)
                .fontColor('#0F172A')
              Text(item.chunkText)
                .width('100%')
                .fontSize(13)
                .fontColor('#334155')
              Text(`distance=${item.distance.toFixed(4)} | vector=${item.vectorText} | id=${item.id}`)
                .width('100%')
                .fontSize(12)
                .fontColor('#64748B')
              Text(item.createdAt)
                .width('100%')
                .fontSize(12)
                .fontColor('#94A3B8')
            }
            .width('100%')
            .padding(14)
            .backgroundColor('#F8FAFC')
            .borderRadius(8)
          }, (item: KnowledgeChunkItem) => `${item.id}`)
        }
        .width('100%')

        Text(this.tips)
          .width('100%')
          .fontSize(13)
          .fontColor('#64748B')
      }
      .width('100%')
      .padding(24)
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#FFFFFF')
    .bindSheet(this.showInfoSheet, this.infoSheet(), {
      height: SheetSize.MEDIUM,
      dragBar: true,
      showClose: true,
      onDisappear: () => {
        this.showInfoSheet = false;
      }
    })
  }
}
