采用华为云Flexus云服务器X实例搭建RTSP服务器【玩转华为云】

举报
DS小龙哥 发表于 2024/09/06 16:38:14 2024/09/06
【摘要】 采用华为云最新推出的Flexus云服务器X实例搭建RTSP服务器,完成视频直播需求。


一、前言

这篇文章讲解: 采用华为云最新推出的Flexus云服务器X实例搭建RTSP服务器,完成视频直播需求。

随着实时视频流传输需求的增长,RTSP(实时流协议)服务器成为了许多视频监控、直播和多媒体应用的核心组件。在当今高度互联的世界中,能够快速部署且稳定运行的RTSP服务器对于确保高质量的视频流体验至关重要。本文将指导如何在华为云Flexus X实例上部署一款轻量级的RTSP服务器——(采用simple-rtsp-server)。

通过本教程,将详细介绍如何在华为云Flexus X实例上安装和配置simple-rtsp-server。simple-rtsp-server以其简单易用的特点而闻名,非常适合那些希望快速搭建起基本RTSP服务的开发者。将涵盖从环境准备到软件安装,再到基本配置的所有步骤,帮助顺利搭建一个可靠的RTSP服务器,为视频流应用提供坚实的基础。

华为云Flexus云服务器X实例是由国家科技进步奖获得者、华为公司Fellow及华为云首席架构师顾炯炯牵头研发的一款创新性云服务器。该实例基于华为的擎天QingTian架构、瑶光云脑和盘古大模型等核心技术,是业界首款应用驱动的柔性算力云服务器,适用于高科技、零售、金融、游戏等多个行业的通用工作负载场景,如网络应用、数据库、虚拟桌面、分析索引、微服务及持续集成/持续部署(CI/CD)等。

传统的云服务器通常只提供固定的CPU和内存规格,无法精准匹配用户的实际资源需求,导致资源利用效率低下。相比之下,华为云Flexus X实例提供了更为灵活的算力配置,支持超过100种不同的CPU与内存配比,最高可达到3:1的比例,从而更好地适应各种业务应用的需求。

Flexus X实例不仅在性能方面表现出色,还内置了智能应用调优算法,结合华为技术专家多年积累的经验,在基础模式下,其GeekBench单核及多核跑分可达业界同规格独享型实例的1.6倍。在性能模式下,Flexus X实例的性能超过了同类C系/G系/R系及S系旗舰型云主机的标准。

此外,Flexus X实例还配备了X-Turbo加速技术和大模型底层智能调度技术,为关键业务应用提供加速功能。例如,在Flexus X实例上部署的MySQL、Redis和Nginx等应用,其性能最高可达业界同规格独享型实例的6倍(MySQL性能),长期运行时也能保持2倍的性能优势。

Flexus X实例在定价策略上定位于经济型级别,但其性能表现却超越了旗舰级云主机。通过动态业务画像规格优化等技术,用户在将业务从本地服务器或其他云服务提供商迁移到Flexus X实例时,可以节省高达30%的算力成本,从而实现业务的全面提速和效能提升,享受到云基础设施的显著改进体验。


二、服务器选购

2.1 登录官网

链接:https://www.huaweicloud.cn/

image-20240905140332361


在官网首页的轮播图里可以看到,有Flexus云服务器的宣传。这是华为云匠心打造的下一代跃级产品,面向中低负载场景,性能倍增、体验跃级的服务器。


2.2 选购服务器

在产品页面,也可以看到Flexus云服务的选项,点击进去选购服务器。

image-20240905140614881


链接:https://www.huaweicloud.cn/product/flexus.html

image-20240905140518001


在选购页面可以看到服务器推广器件,1年36块钱。 每个月的流量是100G,对于一些访问量不高的服务器或者测试用是非常合适的。

image-20240905140827022



当前我要选择的服务器是:Flexus云服务器X实例 ,点击Flexus系列产品,选择X实例。Flexus云服务器X实例符合:柔性算力,六倍性能,旗舰体验,覆盖高科技、零售、金融、游戏等行业大多数通用工作负载场景。

image-20240905142342028


2.3 选择服务器区域

针对时延敏感型业务请选择靠近您业务的区域,以降低网络时延,提高访问速度;针对和存量云产品有内网互通需求的业务,请选择和存量产品相同的区域。

image-20240905142546892



2.4 选择服务器规格

image-20240905143518832



2.5 选择系统镜像

我这选择ubuntu系统,用来搭建服务器。这个根据自己的情况选择,自己适合那一种就选择哪一种。

image-20240905160440609


2.6 选择存储盘

我选择150G大小。

image-20240905154238881


2.7 配置密码

设置好服务器的名字(如果你有多个服务器,为了自己好区别)和系统的登录密码。

image-20240905153958099


2.8 配置云备份

云备份这个不买。有需要自己可以购买。

image-20240905154322590


2.9 确认配置

image-20240905160511662


2.10 立即购买

image-20240905160537231


购买成功。

image-20240905160626605


创建成功之后,邮箱会收到提示的。

image-20240905160724142


2.10 后台控制台

链接:https://console.huaweicloud.cn/ecm


在控制台可以看到服务器的详情。

image-20240905161142694



三、服务器登录

3.1 查看服务器的详情

点击服务器的名称,可以进去到详情页面。

image-20240905161621249


image-20240905161739687


3.2 远程登录

image-20240905161848020


填入设置好的密码。

image-20240905161919502


登录成功。

image-20240905161948036


3.9 采用FinalShell登录

自带的在浏览器里运行,每次需要打开浏览器,文件也不方便上传下载。

所以,这里开发阶段,我采用的 FinalShell登录到服务器。

新建SSH连接,输入连接信息。

image-20240905162205597


登录成功。

image-20240905162444451


接下来就可以进行开发了。


四、搭建RTSP流媒体服务器

4.1 simple-rtsp-server库

simple-rtsp-server依赖ffmpeg,版本要求>=4.x。


GitHub仓库地址:https://github.com/BreakingY/simple-rtsp-server

image-20240905163846205


4.2 安装基础依赖

在命令行运行。

sudo apt-get -y install autoconf automake build-essential libass-dev libfreetype6-dev libsdl2-dev libtheora-dev libtool libva-dev libvdpau-dev libvorbis-dev libxcb1-dev libxcb-shm0-dev libxcb-xfixes0-dev pkg-config texinfo zlib1g-dev


安装过程中:

image-20240905163954528


安装完成。

image-20240905164128024

4.3 安装依赖库

在系统命令行分别运行以下命令,安装依赖库。

汇编库:
sudo apt-get install yasm
sudo apt-get install nasm

视频库:
sudo apt-get install libx264-dev
sudo apt-get install libx265-dev

音频库:
sudo apt-get install libfdk-aac-dev
sudo apt-get install libmp3lame-dev
sudo apt-get install libopus-dev


4.4 安装ffmpeg

下载ffmpeg的库源码。

wget https://ffmpeg.org//releases/ffmpeg-4.0.5.tar.bz2

tar xjvf ffmpeg-4.0.5.tar.bz2

cd ffmpeg-4.0.5

image-20240905164424466



编译ffmpeg库源码。

./configure --prefix=/usr/local --enable-libx264 --disable-x86asm --enable-nonfree --enable-libfdk-aac  --enable-shared --enable-gpl --enable-libmp3lame --enable-libopus  --extra-cflags=-I/usr/local/include --extra-ldflags=-L/usr/local/lib

make

make install


4.5 simple-rtsp-server下载编译


git clone https://github.com/BreakingY/simple-rtsp-server.git

cd simple-rtsp-server

mkdir build

cd build

cmake ..

make -j4

image-20240905165233540


4.6 运行服务器

cp -r ../mp4path .
./rtsp_server loop 0

运行效果:

image-20240905170225684



4.7 开放规则

要记得把服务器的 端口开放出来, 不然无法访问。

image-20240905170441508


image-20240905170457783



4.8 播放测试(RTSP协议播放云端视频文件)

自带了4个测试文件。 可以直接播放。


这是自带的4个测试文件的路径:

root@flexusx-1a58:~/work/simple-rtsp-server# ls mp4path/
test_1280x720_h264_aac.mp4  test_h264_aac.mp4  test_h264_pcma.mkv  test_h265_aac.mp4


下面是播放格式:

rtsp://116.205.107.156:8554/test_1280x720_h264_aac.mp4

其中:

rtsp://<自己的公网IP>:8554/<mp4path目录下的视频文件名称>


下面是potplayer播放器播放的效果:

image-20240905170542053



播放过程中,在服务器上会打印出每个过程的详情。

image-20240906104406331


4.9 rtsp_server.c代码

#include "common.h"
#include "session.h"
#include <arpa/inet.h>
#include <errno.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <sys/socket.h>
#include <unistd.h>
#define BUF_MAX_SIZE (1024 * 1024)
char *mp4Dir = "mp4path/\0"; // MP4文件存放位置
int auth = 1;
#define USER "admin"
#define PASSWORD "123456"
/*doClientThd线程参数*/
struct thd_arg_st
{
    int client_sock_fd;
    char client_ip[30];
    int client_port;
};

int create_rtp_sockets(int *fd1, int *fd2, int *port1, int *port2)
{
    struct sockaddr_in addr;
    int port = 0;

    *fd1 = socket(AF_INET, SOCK_DGRAM, 0);
    if (*fd1 < 0)
    {
        perror("socket");
        return -1;
    }

    *fd2 = socket(AF_INET, SOCK_DGRAM, 0);
    if (*fd2 < 0)
    {
        perror("socket");
        close(*fd1);
        return -1;
    }

    memset(&addr, 0, sizeof(addr));
    addr.sin_family = AF_INET;
    addr.sin_addr.s_addr = htonl(INADDR_ANY);

    for (port = 1024; port <= 65535; port += 2)
    {
        addr.sin_port = htons(port);
        if (bind(*fd1, (struct sockaddr *)&addr, sizeof(addr)) == 0)
        {
            addr.sin_port = htons(port + 1);
            if (bind(*fd2, (struct sockaddr *)&addr, sizeof(addr)) == 0)
            {
                *port1 = port;
                *port2 = port + 1;
                return 0;
            }
            close(*fd1);
        }
    }
    close(*fd1);
    close(*fd2);
    return -1;
}
static void generate_session_id(char *session_id, size_t size) {
    if (size < 9) {
        return;
    }
    time_t timestamp = time(NULL);
    srand((unsigned int)timestamp);
    int random_part = rand() % 1000000;
    snprintf(session_id, size, "%02ld%06d", timestamp % 100, random_part);
    return;
}
/*处理客户端rtsp请求*/
void *doClientThd(void *arg)
{
    signal(SIGINT, sig_handler);
    signal(SIGQUIT, sig_handler);
    signal(SIGKILL, sig_handler);
    struct thd_arg_st *arg_thd = (struct thd_arg_st *)arg;

    int client_sock_fd = arg_thd->client_sock_fd;
    char *client_ip = arg_thd->client_ip;
    int client_port = arg_thd->client_port;
    char method[40];
    char url[100];
    char url_tmp[100];
    char filename[100];
    char url_setup[100];
    char track[1024];
    char url_play[1024];
    char local_ip[40];
    char version[40];
    int cseq;
    char *buf_ptr;
    char *buf_tmp;
    char *recv_buf = malloc(BUF_MAX_SIZE);
    char *send_buf = malloc(BUF_MAX_SIZE);
    char line[400];
    // rtp_over_tcp
    int sig_0 = -1;
    int sig_1 = -1;
    int sig_2 = -1;
    int sig_3 = -1;
    int ture_of_rtp_tcp = 0;
    // rtp_over_udp
    int client_rtp_port = -1;
    int client_rtcp_port = -1;
    int client_rtp_port_1 = -1;
    int client_rtcp_port_1 = -1;
    int server_rtp_port = -1;
    int server_rtcp_port = -1;
    int server_rtp_port_1 = -1;
    int server_rtcp_port_1 = -1;
    int server_udp_socket_rtp_fd = -1;
    int server_udp_socket_rtcp_fd = -1;
    int server_udp_socket_rtp_1_fd = -1;
    int server_udp_socket_rtcp_1_fd = -1;

    char ch = '/';
    int findflag = 0;

    char path[100];
    memcpy(path, mp4Dir, strlen(mp4Dir));
    path[strlen(mp4Dir)] = '\0';

    char path_tmp[100];
    memcpy(path_tmp, mp4Dir, strlen(mp4Dir));
    path_tmp[strlen(mp4Dir)] = '\0';

    int fd;
    char *realm = "simple-rtsp-server";
    char nonce[33] = {0};
    generate_nonce(nonce, sizeof(nonce));
    char session_id[512];
    generate_session_id(session_id, sizeof(session_id));
    while (1)
    {
        int recv_len;

        recv_len = recv(client_sock_fd, recv_buf, BUF_MAX_SIZE, 0);
        if (recv_len <= 0)
            goto out;

        recv_buf[recv_len] = '\0';

        printf("---------------C->S--------------\n");
        printf("%s", recv_buf);

        buf_ptr = getLineFromBuf(recv_buf, line);
        buf_tmp = buf_ptr;

        if (sscanf(line, "%s %s %s\r\n", method, url, version) != 3)
        {
            printf("parse err\n");
            goto out;
        }

        /*解析序列号*/
        while (1)
        {
            buf_ptr = getLineFromBuf(buf_ptr, line);
            if (!strncmp(line, "CSeq:", strlen("CSeq:")))
            {
                if (sscanf(line, "CSeq: %d\r\n", &cseq) != 1)
                {
                    printf("parse err\n");
                    goto out;
                }
                break;
            }
        }
        if(auth == 1){
            // authorization
            if(!strcmp(method, "SETUP") || !strcmp(method, "DESCRIBE") || !strcmp(method, "PLAY")){
                AuthorizationInfo *auth_info = find_authorization(recv_buf);
                if(auth_info == NULL){
                    handleCmd_Unauthorized(send_buf, cseq, realm, nonce);
                    printf("---------------S->C--------------\n");
                    printf("%s", send_buf);
                    send(client_sock_fd, send_buf, strlen(send_buf), 0);
                    continue;
                }
                else{
                    // printf("nonce:%s\n", auth_info->nonce);
                    // printf("realm:%s\n", auth_info->realm);
                    // printf("response:%s\n", auth_info->response);
                    // printf("uri:%s\n", auth_info->uri);
                    // printf("username:%s\n", auth_info->username);
                    // 鉴权校验
                    int ret = authorization_verify(USER, PASSWORD, realm, nonce, auth_info->uri, method, auth_info->response);
                    free_authorization_info(auth_info);
                    if(ret < 0){ // 鉴权失败
                        goto out;
                    }
                }
            }
        }

        /* 如果是SETUP,需要解析是RTP_OVER_TCP还是RTP_OVER_UDP模式 */
        if (!strcmp(method, "SETUP"))
        {
            memset(url_setup, 0, sizeof(url_setup));
            memset(track, 0, sizeof(track));
            strcpy(url_setup, url);
            char *p = strrchr(url_setup, ch);
            memcpy(track, p + 1, strlen(p)); // video-track0 audio -track1
            while (1)
            {
                buf_tmp = getLineFromBuf(buf_tmp, line);

                if (!buf_tmp)
                {
                    break;
                }

                if (!strncmp(line, "Transport: RTP/AVP/TCP", strlen("Transport: RTP/AVP/TCP")))
                {

                    if (memcmp(track, "track0", 6) == 0)
                    {
                        sscanf(line, "Transport: RTP/AVP/TCP;unicast;interleaved=%d-%d\r\n", &sig_0, &sig_1);
                    }
                    else
                    {
                        sscanf(line, "Transport: RTP/AVP/TCP;unicast;interleaved=%d-%d\r\n", &sig_2, &sig_3);
                    }

                    ture_of_rtp_tcp = 1;
                    break;
                }
                if (!strncmp(line, "Transport: RTP/AVP/UDP", strlen("Transport: RTP/AVP/UDP")))
                {
                    if (memcmp(track, "track0", 6) == 0)
                    {
                        sscanf(line, "Transport: RTP/AVP/UDP;unicast;client_port=%d-%d\r\n", &client_rtp_port, &client_rtcp_port);
                    }
                    else
                    {
                        sscanf(line, "Transport: RTP/AVP/UDP;unicast;client_port=%d-%d\r\n", &client_rtp_port_1, &client_rtcp_port_1);
                    }
                    break;
                }
                if (!strncmp(line, "Transport: RTP/AVP", strlen("Transport: RTP/AVP")))
                {

                    if (memcmp(track, "track0", 6) == 0)
                    {
                        sscanf(line, "Transport: RTP/AVP;unicast;client_port=%d-%d\r\n", &client_rtp_port, &client_rtcp_port);
                    }
                    else
                    {
                        sscanf(line, "Transport: RTP/AVP;unicast;client_port=%d-%d\r\n", &client_rtp_port_1, &client_rtcp_port_1);
                    }
                    break;
                }
            }
        }
        if (!strcmp(method, "OPTIONS"))
        {
            char *p = strrchr(url, ch);
            memcpy(filename, p + 1, strlen(p));

            char *tmp = strcat(path_tmp, filename);
            findflag = 1;
            fd = open(tmp, O_RDONLY);
            if (fd < 0) // 请求的资源不存在返回404并关闭客户端文件描述符
            {
                perror("failed");
                handleCmd_404(send_buf, cseq);
                send(client_sock_fd, send_buf, strlen(send_buf), 0);
                goto out;
            }
            else
            {
                close(fd);
                if (handleCmd_OPTIONS(send_buf, cseq))
                {
                    printf("failed to handle options\n");
                    goto out;
                }
            }
        }
        else if (!strcmp(method, "DESCRIBE"))
        {
            if (findflag == 0)
            {
                char *p = strrchr(url, ch);
                memcpy(filename, p + 1, strlen(p));

                char *tmp = strcat(path_tmp, filename);
                fd = open(tmp, O_RDONLY);
                if (fd < 0) // 请求的资源不存在返回404并关闭客户端文件描述符
                {
                    perror("failed");
                    handleCmd_404(send_buf, cseq);
                    send(client_sock_fd, send_buf, strlen(send_buf), 0);
                    goto out;
                }
                close(fd);
                findflag = 1;
            }
            char sdp[1024];
            char localIp[100];
            sscanf(url, "rtsp://%[^:]:", localIp);
            int ret = generateSDP(path_tmp, localIp, sdp, sizeof(sdp));
            if (ret < 0)
            { // mp4文件有问题,或者视频不是H264/H265,音频不是AAC/PCMA
                handleCmd_500(send_buf, cseq);
                send(client_sock_fd, send_buf, strlen(send_buf), 0);
                goto out;
            }
            if (handleCmd_DESCRIBE(send_buf, cseq, url, sdp))
            {
                printf("failed to handle describe\n");
                goto out;
            }
        }
        else if (!strcmp(method, "SETUP") && ture_of_rtp_tcp == 0) // RTP_OVER_UDP
        {
            sscanf(url, "rtsp://%[^:]:", local_ip);
            if (memcmp(track, "track0", 6) == 0)
            {
                create_rtp_sockets(&server_udp_socket_rtp_fd, &server_udp_socket_rtcp_fd, &server_rtp_port, &server_rtp_port);
                handleCmd_SETUP_UDP(send_buf, cseq, client_rtp_port, server_rtp_port, session_id);
            }
            else
            {
                create_rtp_sockets(&server_udp_socket_rtp_1_fd, &server_udp_socket_rtcp_1_fd, &server_rtp_port_1, &server_rtp_port_1);
                handleCmd_SETUP_UDP(send_buf, cseq, client_rtp_port_1, server_rtp_port_1, session_id);
            }
        }
        else if (!strcmp(method, "SETUP") && ture_of_rtp_tcp == 1) // RTP_OVER_TCP
        {
            sscanf(url, "rtsp://%[^:]:", local_ip);
            if (memcmp(track, "track0", 6) == 0)
            {
                handleCmd_SETUP_TCP(send_buf, cseq, local_ip, client_ip, sig_0, session_id);
            }
            else
            {
                handleCmd_SETUP_TCP(send_buf, cseq, local_ip, client_ip, sig_2, session_id);
            }
        }
        else if (!strcmp(method, "PLAY"))
        {
            memset(url_play, 0, sizeof(url_play));
            memset(track, 0, sizeof(track));
            strcpy(url_play, url);
            if (handleCmd_PLAY(send_buf, cseq, url_play, session_id))
            {
                printf("failed to handle play\n");
                goto out;
            }
        }
        else
        {
            goto out;
        }

        printf("---------------S->C--------------\n");
        printf("%s", send_buf);

        send(client_sock_fd, send_buf, strlen(send_buf), 0);

        if (!strcmp(method, "PLAY"))
        {
            struct timeval time_pre, time_now;
            gettimeofday(&time_pre, NULL);

            char *tmp = strcat(path, filename);
            int ret = addClient(tmp, client_sock_fd, sig_0, sig_2, ture_of_rtp_tcp, client_ip, client_rtp_port, client_rtp_port_1,
                                server_udp_socket_rtp_fd, server_udp_socket_rtcp_fd, server_udp_socket_rtp_1_fd, server_udp_socket_rtcp_1_fd);
            if (ret < 0)
                goto out;
            int sum = getClientNum();

            gettimeofday(&time_now, NULL);
            int time_handle = 1000 * (time_now.tv_sec - time_pre.tv_sec) + (time_now.tv_usec - time_pre.tv_usec) / 1000;
            printf("timeuse:%dms sum_client:%d\n\n", time_handle, sum);
            goto over;
        }
    }
out:
    close(client_sock_fd);
    free(recv_buf);
    free(send_buf);
    free(arg);
    return NULL;
over:

    free(recv_buf);
    free(send_buf);
    free(arg);
    return NULL;
}

int main(int argc, char *argv[])
{
    if(argc < 3){
        printf("./rtsp_server auth(0-not authentication; 1-authentication) loop(0-not loop 1-loop)\n");
        return -1;
    }
    auth = atoi(argv[1]);
    reloop_flag = atoi(argv[2]);
    int server_sock_fd;
    int ret;
    signal(SIGINT, sig_handler);
    signal(SIGQUIT, sig_handler);
    signal(SIGKILL, sig_handler);

    signal(SIGPIPE, SIG_IGN);
    signal(SIGFPE, SIG_IGN);

    server_sock_fd = createTcpSocket();
    if (server_sock_fd < 0)
    {
        printf("failed to create tcp socket\n");
        return -1;
    }

    ret = bindSocketAddr(server_sock_fd, SERVER_IP, SERVER_PORT);
    if (ret < 0)
    {
        printf("failed to bind addr\n");
        return -1;
    }

    ret = listen(server_sock_fd, 100);
    if (ret < 0)
    {
        printf("failed to listen\n");
        return -1;
    }

    moduleInit();

    printf("rtsp://%s:%d/filename\n", SERVER_IP, SERVER_PORT);
    while (1)
    {
        int client_sock_fd;
        char client_ip[40];
        int client_port;
        pthread_t tid;

        client_sock_fd = acceptClient(server_sock_fd, client_ip, &client_port);
        if (client_sock_fd < 0)
        {
            printf("failed to accept client\n");
            return -1;
        }
        printf("###########accept client --> client_sock_fd:%d client ip:%s,client port:%d###########\n", client_sock_fd, client_ip, client_port);
        struct thd_arg_st *arg;
        arg = malloc(sizeof(struct thd_arg_st));
        memcpy(arg->client_ip, client_ip, strlen(client_ip));
        arg->client_port = client_port;
        arg->client_sock_fd = client_sock_fd;

        ret = pthread_create(&tid, NULL, doClientThd, (void *)arg);
        if (ret < 0)
        {
            perror("doClientThd pthread_create()");
        }
        pthread_detach(tid);
    }
    moduleDel();
    close(server_sock_fd);
    return 0;
}


4.10 common.c 代码

#include "common.h"
#include "md5.h"
#include <arpa/inet.h>
#include <assert.h>
#include <errno.h>
#include <fcntl.h>
#include <libavcodec/avcodec.h>
#include <libavformat/avformat.h>
#include <libavutil/log.h>
#include <libavutil/time.h>
#include <netinet/in.h>
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <sys/socket.h>
#include <sys/stat.h>
#include <sys/types.h>
#include <unistd.h>
int createTcpSocket()
{
    int sockfd;
    int on = 1;

    sockfd = socket(AF_INET, SOCK_STREAM, 0);
    if (sockfd < 0)
        return -1;
    setsockopt(sockfd, SOL_SOCKET, SO_REUSEADDR, (const char *)&on, sizeof(on));
    return sockfd;
}
int createUdpSocket()
{
    int sockfd;
    int on = 1;
    sockfd = socket(AF_INET, SOCK_DGRAM, 0);
    if (sockfd < 0)
        return -1;
    setsockopt(sockfd, SOL_SOCKET, SO_REUSEADDR, (const char *)&on, sizeof(on));
    return sockfd;
}

int bindSocketAddr(int sockfd, const char *ip, int port)
{
    struct sockaddr_in addr;
    addr.sin_family = AF_INET;
    addr.sin_port = htons(port);
    addr.sin_addr.s_addr = inet_addr(ip);
    if (bind(sockfd, (struct sockaddr *)&addr, sizeof(struct sockaddr)) < 0)
        return -1;
    return 0;
}
int acceptClient(int sockfd, char *ip, int *port)
{
    int clientfd;
    socklen_t len = 0;
    struct sockaddr_in addr;
    memset(&addr, 0, sizeof(addr));
    len = sizeof(addr);
    clientfd = accept(sockfd, (struct sockaddr *)&addr, &len);
    if (clientfd < 0)
    {
        printf("accept err:%s\n", strerror(errno));
        return -1;
    }
    strcpy(ip, inet_ntoa(addr.sin_addr));
    *port = ntohs(addr.sin_port);

    return clientfd;
}
void rtpHeaderInit(struct RtpPacket *rtpPacket, uint8_t csrcLen, uint8_t extension,
                   uint8_t padding, uint8_t version, uint8_t payloadType, uint8_t marker,
                   uint16_t seq, uint32_t timestamp, uint32_t ssrc)
{
    rtpPacket->rtpHeader.csrcLen = csrcLen;
    rtpPacket->rtpHeader.extension = extension;
    rtpPacket->rtpHeader.padding = padding;
    rtpPacket->rtpHeader.version = version;
    rtpPacket->rtpHeader.payloadType = payloadType;
    rtpPacket->rtpHeader.marker = marker;
    rtpPacket->rtpHeader.seq = seq;
    rtpPacket->rtpHeader.timestamp = timestamp;
    rtpPacket->rtpHeader.ssrc = ssrc;
    return;
}

char *getLineFromBuf(char *buf, char *line)
{
    while (*buf != '\n')
    {
        *line = *buf;
        line++;
        buf++;
    }

    *line = '\n';
    ++line;
    *line = '\0';

    ++buf;
    return buf;
}
static char *extract_value(const char *source, const char *key) {
    const char *start = strstr(source, key);
    if (!start) {
        return NULL;
    }
    start += strlen(key) + 2; // 跳过 key="

    const char *end = strchr(start, '"');
    if (!end) {
        return NULL;
    }

    size_t len = end - start;
    char *value = (char *)malloc(len + 1);
    if (!value) {
        return NULL;
    }

    strncpy(value, start, len);
    value[len] = '\0';
    return value;
}

AuthorizationInfo *find_authorization(const char *request) {
    const char *auth_start = strstr(request, "Authorization: ");
    if (!auth_start) {
        return NULL; // Authorization字段未找到
    }

    auth_start += strlen("Authorization: ");
    const char *auth_end = strchr(auth_start, '\r');
    if (!auth_end) {
        auth_end = strchr(auth_start, '\n');
    }
    if (!auth_end) {
        return NULL; // 无法找到行尾
    }

    char *auth_value = (char *)malloc(auth_end - auth_start + 1);
    if (!auth_value) {
        return NULL; // 内存分配失败
    }
    strncpy(auth_value, auth_start, auth_end - auth_start);
    auth_value[auth_end - auth_start] = '\0';

    AuthorizationInfo *auth_info = (AuthorizationInfo *)malloc(sizeof(AuthorizationInfo));
    if (!auth_info) {
        free(auth_value);
        return NULL; // 内存分配失败
    }

    auth_info->username = extract_value(auth_value, "username");
    auth_info->realm = extract_value(auth_value, "realm");
    auth_info->nonce = extract_value(auth_value, "nonce");
    auth_info->uri = extract_value(auth_value, "uri");
    auth_info->response = extract_value(auth_value, "response");

    free(auth_value);
    return auth_info;
}

void free_authorization_info(AuthorizationInfo *auth_info) {
    if (auth_info) {
        free(auth_info->username);
        free(auth_info->realm);
        free(auth_info->nonce);
        free(auth_info->uri);
        free(auth_info->response);
        free(auth_info);
    }
    return;
}
// 生成随机字符串
static void generate_random_string(char *buf, int length) {
    static const char charset[] = "abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789";
    for (size_t i = 0; i < length; i++) {
        buf[i] = charset[rand() % (sizeof(charset) - 1)];
    }
    return;
}

// 生成nonce
void generate_nonce(char *nonce, int length) {
    if (length < 1) {
        nonce[0] = '\0';
        return;
    }
    memset(nonce, 0, length);
    srand((unsigned int)time(NULL));

    char random_string[128] = {0};
    generate_random_string(random_string, sizeof(random_string));

    char timestamp[32];
    snprintf(timestamp, sizeof(timestamp), "%ld", (long)time(NULL));

    char combined[256] = {0};
    snprintf(combined, sizeof(combined), "%s%s", random_string, timestamp);

    MD5_CTX md5;
    unsigned char decrypt[16];
    MD5Init(&md5);
    MD5Update(&md5, combined, strlen(combined));
    MD5Final(&md5, decrypt);
    for(int i = 0; i < 16; i++) {
        snprintf(&(nonce[i * 2]), 3, "%02x", decrypt[i]);
    }
    return;
}

int authorization_verify(char *username, char *password, char *realm, char *nonce, char *uri, char * method, char *response){
    // md5(username:realm:password)
    unsigned char res1[16];
    char res1_hex[33] = {0};
    char buffer1[256] = {0};
    sprintf(buffer1,"%s:%s:%s", username, realm, password);
    MD5_CTX md5_1;
    MD5Init(&md5_1);
    MD5Update(&md5_1, buffer1, strlen(buffer1));
    MD5Final(&md5_1, res1);
    for(int i = 0; i < 16; i++) {
        snprintf(&(res1_hex[i * 2]), 3, "%02x", res1[i]);
    }
    // md5(public_method:url)
    unsigned char res2[16];
    char res2_hex[33] = {0};
    char buffer2[256] = {0};
    sprintf(buffer2,"%s:%s", method, uri);
    MD5_CTX md5_2;
    MD5Init(&md5_2);
    MD5Update(&md5_2, buffer2, strlen(buffer2));
    MD5Final(&md5_2, res2);
    for(int i = 0; i < 16; i++) {
        snprintf(&(res2_hex[i * 2]), 3, "%02x", res2[i]);
    }
    // md5( md5(username:realm:password):nonce:md5(public_method:url) )
    unsigned char res[16];
    char res_hex[33] = {0};
    char buffer[512] = {0};
    sprintf(buffer,"%s:%s:%s", res1_hex, nonce, res2_hex);
    MD5_CTX md5;
    MD5Init(&md5);
    MD5Update(&md5, buffer, strlen(buffer));
    MD5Final(&md5, res);
    for(int i = 0; i < 16; i++) {
        snprintf(&(res_hex[i * 2]), 3, "%02x", res[i]);
    }
    // printf("res:%s response:%s\n", res_hex, response);
    if(strcmp(res_hex, response) == 0){
        return 0;
    }
    return -1;
}

int handleCmd_Unauthorized(char *result, int cseq, char *realm, char *nonce){
	sprintf(result, "RTSP/1.0 401 Unauthorized\r\n"
			        "CSeq: %d\r\n"
			        "WWW-Authenticate: Digest realm=\"%s\", nonce=\"%s\"\r\n"
			        "\r\n",
                cseq,
                realm,
                nonce);

	return 0;
}
int handleCmd_OPTIONS(char *result, int cseq)
{
    sprintf(result, "RTSP/1.0 200 OK\r\n"
                    "CSeq: %d\r\n"
                    "Public: OPTIONS, DESCRIBE, SETUP, PLAY\r\n"
                    "\r\n",
            cseq);

    return 0;
}
int handleCmd_DESCRIBE(char *result, int cseq, char *url, char *sdp)
{
    sprintf(result, "RTSP/1.0 200 OK\r\nCSeq: %d\r\n"
                    "Content-Base: %s\r\n"
                    "Content-type: application/sdp\r\n"
                    "Content-length: %d\r\n\r\n"
                    "%s",
            cseq,
            url,
            strlen(sdp),
            sdp);

    return 0;
}
int handleCmd_SETUP_TCP(char *result, int cseq, char *localIp, char *clientIp, int sig_0, char *session)
{
    sprintf(result, "RTSP/1.0 200 OK\r\n"
                    "CSeq: %d\r\n"
                    "Transport: RTP/AVP/TCP;unicast;destination=%s;source=%s;interleaved=%d-%d\r\n"
                    "Session: %s\r\n"
                    "\r\n",
            cseq,
            clientIp,
            localIp,
            sig_0,
            sig_0 + 1,
            session);

    return 0;
}
int handleCmd_SETUP_UDP(char *result, int cseq, int clientRtpPort, int serverRtpPort, char *session)
{
    sprintf(result, "RTSP/1.0 200 OK\r\n"
                    "CSeq: %d\r\n"
                    "Transport: RTP/AVP;unicast;client_port=%d-%d;server_port=%d-%d\r\n"
                    "Session: %s\r\n"
                    "\r\n",
            cseq,
            clientRtpPort,
            clientRtpPort + 1,
            serverRtpPort,
            serverRtpPort + 1,
            session);

    return 0;
}
int handleCmd_PLAY(char *result, int cseq, char *url_setup, char *session)
{
    sprintf(result, "RTSP/1.0 200 OK\r\n"
                    "CSeq: %d\r\n"
                    "Range: npt=0.000-\r\n"
                    "Session: %s; timeout=60\r\n\r\n",
            cseq,
            session);

    return 0;
}
int handleCmd_404(char *result, int cseq)
{
    sprintf(result, "RTSP/1.0 404 NOT FOUND\r\n"
                    "CSeq: %d\r\n"
                    "\r\n",
            cseq);

    return 0;
}
int handleCmd_500(char *result, int cseq)
{
    sprintf(result, "RTSP/1.0 500 SERVER ERROR\r\n"
                    "CSeq: %d\r\n"
                    "\r\n",
            cseq);

    return 0;
}
int check_media_info(const char *filename, MediaInfo *info)
{
    AVFormatContext *format_ctx = NULL;
    int ret;

    if ((ret = avformat_open_input(&format_ctx, filename, NULL, NULL)) < 0)
    {
        fprintf(stderr, "Could not open source file %s\n", filename);
        return ret;
    }
    if ((ret = avformat_find_stream_info(format_ctx, NULL)) < 0)
    {
        fprintf(stderr, "Could not find stream information\n");
        avformat_close_input(&format_ctx);
        return ret;
    }

    info->has_audio = 0;
    info->has_video = 0;
    info->is_video_h26x = 0;
    info->is_audio_aac_pcma = 0;
    info->audio_sample_rate = 0;
    info->audio_channels = 0;
    // info->vps = NULL;
    // info->sps = NULL;
    // info->pps = NULL;
    // info->vps_size = 0;
    // info->sps_size = 0;
    // info->pps_size = 0;

    for (unsigned int i = 0; i < format_ctx->nb_streams; i++)
    {
        AVStream *stream = format_ctx->streams[i];
        AVCodecParameters *codecpar = stream->codecpar;

        if (codecpar->codec_type == AVMEDIA_TYPE_VIDEO)
        {
            info->has_video = 1;
            if (codecpar->codec_id == AV_CODEC_ID_H264 || codecpar->codec_id == AV_CODEC_ID_H265 || codecpar->codec_id == AV_CODEC_ID_HEVC)
            {
                info->is_video_h26x = 1;
                if (codecpar->codec_id == AV_CODEC_ID_H264)
                    info->video_type = H264;
                else
                    info->video_type = H265;
            }
        }
        else if (codecpar->codec_type == AVMEDIA_TYPE_AUDIO)
        {
            info->has_audio = 1;
            if (codecpar->codec_id == AV_CODEC_ID_AAC || codecpar->codec_id == AV_CODEC_ID_PCM_ALAW)
            {
                info->is_audio_aac_pcma = 1;
                info->audio_sample_rate = codecpar->sample_rate;
                info->audio_channels = codecpar->channels;
                info->profile = codecpar->profile;
                if(codecpar->codec_id == AV_CODEC_ID_AAC)
                    info->audio_type = AAC;
                else
                    info->audio_type = PCMA;
            }
        }
    }
    avformat_close_input(&format_ctx);

    return 0;
}
void free_media_info(MediaInfo *info)
{
    // if (info->vps)
    // {
    //     free(info->vps);
    // }
    // if (info->sps)
    // {
    //     free(info->sps);
    // }
    // if (info->pps)
    // {
    //     free(info->pps);
    // }
    return;
}
/*
#define FF_PROFILE_AAC_MAIN 0
#define FF_PROFILE_AAC_LOW  1
#define FF_PROFILE_AAC_SSR  2
#define FF_PROFILE_AAC_LTP  3
#define FF_PROFILE_AAC_HE   4
#define FF_PROFILE_AAC_HE_V2 28
#define FF_PROFILE_AAC_LD   22
#define FF_PROFILE_AAC_ELD  38
#define FF_PROFILE_MPEG2_AAC_LOW 128
#define FF_PROFILE_MPEG2_AAC_HE  131
*/
static int get_audio_obj_type(int aactype){
    //AAC HE V2 = AAC LC + SBR + PS
    //AAV HE = AAC LC + SBR
    //所以无论是 AAC_HEv2 还是 AAC_HE 都是 AAC_LC
    switch(aactype){
        case 0:
        case 2:
        case 3:
            return aactype + 1;
        case 1:
        case 4:
        case 28:
            return 2;
        default:
            return 2;

    }
    return 2;
}

static int get_sample_rate_index(int freq, int aactype){

    int i = 0;
    int freq_arr[13] = {
        96000, 88200, 64000, 48000, 44100, 32000,
        24000, 22050, 16000, 12000, 11025, 8000, 7350
    };

    //如果是 AAC HEv2 或 AAC HE, 则频率减半
    if(aactype == 28 || aactype == 4){
        freq /= 2;
    }

    for(i = 0; i < 13; i++){
        if(freq == freq_arr[i]){
            return i;
        }
    }
    return 4;//默认是44100
}

static int get_channel_config(int channels, int aactype){
    //如果是 AAC HEv2 通道数减半
    if(aactype == 28){
        return (channels / 2);
    }
    return channels;
}
int generateSDP(char *file, char *localIp, char *buffer, int buffer_len)
{
    memset(buffer, 0, buffer_len);
    MediaInfo info;
    if (check_media_info(file, &info) != 0)
    {
        printf("server error\n");
        free_media_info(&info);
        return -1;
    }
    if (info.has_video && !info.is_video_h26x)
    {
        printf("only support h264 h265\n");
        free_media_info(&info);
        return -1;
    }
    if (info.has_audio && !info.is_audio_aac_pcma)
    {
        printf("only support aac pcma\n");
        free_media_info(&info);
        return -1;
    }
    sprintf(buffer, "v=0\r\n"
                    "o=- 9%ld 1 IN IP4 %s\r\n"
                    "c=IN IP4 %s\r\n"
                    "t=0 0\r\n"
                    "a=control:*\r\n",
            time(NULL), localIp, localIp);
    if (info.has_video)
    {
        sprintf(buffer + strlen(buffer), "m=video 0 RTP/AVP %d\r\n"
                                         "a=rtpmap:%d %s/90000\r\n"
                                         //"a=fmtp:%d profile-level-id=42A01E; packetization-mode=1; sprop-parameter-sets=Z0IACpZTBYmI,aMljiA==\r\n"
                                         "a=fmtp:%d packetization-mode=1\r\n"
                                         "a=control:track0\r\n",
                RTP_PAYLOAD_TYPE_H26X, RTP_PAYLOAD_TYPE_H26X, info.video_type == H264 ? "H264" : "H265", RTP_PAYLOAD_TYPE_H26X);
    }
    if (info.has_audio)
    {
        if (info.audio_type == AAC)
        {
            char config[10] = {0};
            int index = get_sample_rate_index(info.audio_sample_rate, info.profile);
            sprintf(config, "%02x%02x", (uint8_t)((get_audio_obj_type(info.profile)) << 3)|(index >> 1), (uint8_t)((index << 7)|(info.audio_channels << 3)));
            sprintf(buffer + strlen(buffer), "m=audio 0 RTP/AVP %d\r\n"
                                             "a=rtpmap:%d MPEG4-GENERIC/%u/%u\r\n"
                                             "a=fmtp:%d streamtype=5;profile-level-id=1;mode=AAC-hbr;config=%04u;sizelength=13;indexlength=3;indexdeltalength=3\r\n"
                                             "a=control:track1\r\n",
                    RTP_PAYLOAD_TYPE_AAC, RTP_PAYLOAD_TYPE_AAC, info.audio_sample_rate, info.audio_channels, RTP_PAYLOAD_TYPE_AAC, atoi(config));
        }
        else
        {
            sprintf(buffer + strlen(buffer), "m=audio 0 RTP/AVP %d\r\n"
                                             "a=rtpmap:%d PCMA/%u/%u\r\n"
                                             "a=control:track1\r\n",
                    RTP_PAYLOAD_TYPE_PCMA, RTP_PAYLOAD_TYPE_PCMA, info.audio_sample_rate, info.audio_channels);
        }
    }
    free_media_info(&info);
    return 0;
}
// aactype = ffmpeg --> AVCodecParameters *codecpar->profile
void adts_header(char *adts_header_buffer, int data_len, int aactype, int frequency, int channels){

    int audio_object_type = get_audio_obj_type(aactype);
    int sampling_frequency_index = get_sample_rate_index(frequency, aactype);
    int channel_config = get_channel_config(channels, aactype);

    int adts_len = data_len + 7;

    adts_header_buffer[0] = 0xff;         //syncword:0xfff                          高8bits
    adts_header_buffer[1] = 0xf0;         //syncword:0xfff                          低4bits
    adts_header_buffer[1] |= (0 << 3);    //MPEG Version:0 for MPEG-4,1 for MPEG-2  1bit
    adts_header_buffer[1] |= (0 << 1);    //Layer:0                                 2bits
    adts_header_buffer[1] |= 1;           //protection absent:1                     1bit

    adts_header_buffer[2] = (audio_object_type - 1)<<6;            //profile:audio_object_type - 1                      2bits
    adts_header_buffer[2] |= (sampling_frequency_index & 0x0f)<<2; //sampling frequency index:sampling_frequency_index  4bits
    adts_header_buffer[2] |= (0 << 1);                             //private bit:0                                      1bit
    adts_header_buffer[2] |= (channel_config & 0x04)>>2;           //channel configuration:channel_config               高1bit

    adts_header_buffer[3] = (channel_config & 0x03)<<6;     //channel configuration:channel_config      低2bits
    adts_header_buffer[3] |= (0 << 5);                      //original:0                               1bit
    adts_header_buffer[3] |= (0 << 4);                      //home:0                                   1bit
    adts_header_buffer[3] |= (0 << 3);                      //copyright id bit:0                       1bit
    adts_header_buffer[3] |= (0 << 2);                      //copyright id start:0                     1bit
    adts_header_buffer[3] |= ((adts_len & 0x1800) >> 11);           //frame length:value   高2bits

    adts_header_buffer[4] = (uint8_t)((adts_len & 0x7f8) >> 3);     //frame length:value    中间8bits
    adts_header_buffer[5] = (uint8_t)((adts_len & 0x7) << 5);       //frame length:value    低3bits
    adts_header_buffer[5] |= 0x1f;                                 //buffer fullness:0x7ff 高5bits
    adts_header_buffer[6] = 0xfc;
    return;
}


五、总结

华为云正在举行其年度828 B2B企业节活动,期间提供了包括Flexus X实例在内的多种产品的优惠。对于那些对计算性能有较高要求,并且需要自行部署MySQL、Redis、Nginx等服务的用户来说,这次促销是一个很好的机会,建议有兴趣的朋友可以前往查看相关的优惠信息。

官网直达:https://activity.huaweicloud.cn/828_promotion/index.html

image-20240906111030734

【版权声明】本文为华为云社区用户原创内容,转载时必须标注文章的来源(华为云社区)、文章链接、文章作者等基本信息, 否则作者和本社区有权追究责任。如果您发现本社区中有涉嫌抄袭的内容,欢迎发送邮件进行举报,并提供相关证据,一经查实,本社区将立刻删除涉嫌侵权内容,举报邮箱: cloudbbs@huaweicloud.com
  • 点赞
  • 收藏
  • 关注作者

评论(0

0/1000
抱歉,系统识别当前为高风险访问,暂不支持该操作

全部回复

上滑加载中

设置昵称

在此一键设置昵称,即可参与社区互动!

*长度不超过10个汉字或20个英文字符,设置后3个月内不可修改。

*长度不超过10个汉字或20个英文字符,设置后3个月内不可修改。
