WorldView-2和WorldView-3图像（每像素2米）制作的美国南部海岸湿地地区土地覆盖变化的可视化和比较应用

//////////////////////////////////////////////////////////////////////////////////////////////////////////
//////////////    High-res wetland cover of the Northern Gulf of Mexico and Florida APP    ///////////////
//////////////                              For Basic Use                                  ///////////////
//////////////////////////////////////////////////////////////////////////////////////////////////////////

// Script by: Luis Lizcano-Sandoval
// College of Marine Science, University of South Florida
// Date: 11/12/2020
// Contact: luislizcanos@usf.edu


// Load some datasets.
var tile_coverage = ee.FeatureCollection("users/lizcanosandoval/wv-regions/tile_coverage");
var density = ee.Image("users/lizcanosandoval/wv-regions/Region_Density");
var regions = ee.FeatureCollection("users/lizcanosandoval/wv-regions/wv_counties_buffer");

// Set static variables for months and years.
var month = {
  'Jan' : ['01-01', '01-31'],
  'Feb' : ['02-01', '02-28'],
  'Mar' : ['03-01', '03-31'],
  'Apr' : ['04-01', '04-30'],
  'May' : ['05-01', '05-31'],
  'Jun' : ['06-01', '06-30'],
  'Jul' : ['07-01', '07-31'],
  'Aug' : ['08-01', '08-31'],
  'Sep' : ['09-01', '09-30'],
  'Oct' : ['10-01', '10-31'],
  'Nov' : ['11-01', '11-30'],
  'Dec' : ['12-01', '12-31']
  };
var year = ['2009','2010','2011','2012','2013','2014','2015','2016','2017','2018'];

// Dictionary of classes:
var pixelClass = {
  'All' : 0,
  'Soil' : 2,
  'Water' : 3,
  'Dead Grass' : 5,
  'Marsh' : 6,
  'Scrub' : 7,
  'Grass' : 8,
  'Forested Upland' : 9,
  'Forested Wetland' : 10,
  'Developed' : 11,
  };

// Import image collection:
var wetlands = ee.ImageCollection("projects/imars-3d-wetlands/alabama")
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_big_bend"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_monroe"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_ne"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_panhandle"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_se"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/fl_sw"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/louisiana_e"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/louisiana_w"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/mississippi"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/texas_central"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/texas_ne"))
  .merge(ee.ImageCollection("projects/imars-3d-wetlands/texas_sw"));

//Import DEM collection:
var dem = ee.ImageCollection("projects/imars-3d-wetlands/DEM_GoM");
var dem_cover = ee.Image("projects/imars-3d-wetlands/DEM_coverage100");

// Styles for map layers
var region_STYLE = {color: '#00006E', fillColor: '#1569C7', width: 1};
var highlight_STYLE = {color: '8856a7', fillColor: '8856a7C0'};
var tile_STYLE = {color: '#000000', fillColor: '#736F6E', width: 1};
var densityPalette = [
  "#FFEBEB",
  "#FFCFCF",
  "#FF7D7D",
  "#FF4141",
  "#FF0000",
  "#CD0000",
  "#950000",
  "#780000",
  "#5F0000"
  ];

/////////////////////////////////////////////////////////
var leftMap = ui.Map();
var rightMap = ui.Map();

// Configure our map with a minimal set of controls.
leftMap.setControlVisibility(true);
leftMap.setControlVisibility({scaleControl: true, zoomControl: true});
leftMap.style().set({cursor: 'crosshair'});
leftMap.setCenter(-89.27, 27.49, 6);
rightMap.setControlVisibility(true);
rightMap.setControlVisibility({scaleControl: true, zoomControl: true});
rightMap.style().set({cursor: 'crosshair'});
//rightMap.setCenter(-89.27, 27.49, 6);

// Create the application title bar.
var clickTitleL = ui.Label('Click on Regions of Interest', {fontWeight: 'bold', fontSize: '18px',position:'top-center'});
var clickTitleR = ui.Label('Click on Regions of Interest', {fontWeight: 'bold', fontSize: '18px',position:'top-center'});
leftMap.add(clickTitleL);
rightMap.add(clickTitleR);

// Add layers to the map
leftMap.addLayer(regions.style(region_STYLE), {opacity: 0.7}, 'Counties');
leftMap.layers().set(1, ui.Map.Layer(tile_coverage.style(tile_STYLE), {opacity: 0.4}, 'Coverage',false));
leftMap.layers().set(2, ui.Map.Layer(density, {min:1, max:200, palette: densityPalette}, 'Tile Density',false,0.8));
leftMap.layers().set(3, ui.Map.Layer(dem_cover,{palette: '#e5ff58'},'DEM Coverage',false,0.6));

rightMap.addLayer(regions.style(region_STYLE), {opacity: 0.7}, 'Counties');
rightMap.layers().set(1, ui.Map.Layer(tile_coverage.style(tile_STYLE), {opacity: 0.4}, 'Coverage',false));
rightMap.layers().set(2, ui.Map.Layer(density, {min:1, max:200, palette: densityPalette}, 'Tile Density',false,0.8));
rightMap.layers().set(3, ui.Map.Layer(dem_cover,{palette: '#e5ff58'},'DEM Coverage',false,0.6));


/// LAYER CHECKBOX:

// Create a panel to hold the chart.
var layerPanel_left = ui.Panel();
layerPanel_left.style().set({
  width: '150px',
  position: 'bottom-left',
  backgroundColor: 'rgba(255, 255, 255, 0.7)'
});
var layerPanel_right = ui.Panel();
layerPanel_right.style().set({
  width: '150px',
  position: 'bottom-right',
  backgroundColor: 'rgba(255, 255, 255, 0.7)'
});

// Add panels to the map.
leftMap.add(layerPanel_left);
rightMap.add(layerPanel_right);

// Create checkboxes.
// Left side:
var checkbox1_left = ui.Checkbox('Tile Coverage', false);
checkbox1_left.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox1_left.onChange(function(checked) {
  // Shows or hides the map layer based on the checkbox's value.
  leftMap.layers().get(1).setShown(checked);
});
var checkbox2_left = ui.Checkbox('Tile Density', false);
checkbox2_left.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox2_left.onChange(function(checked) {
  leftMap.layers().get(2).setShown(checked);
});
var checkbox3_left = ui.Checkbox('DEM Coverage', false);
checkbox3_left.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox3_left.onChange(function(checked) {
  leftMap.layers().get(3).setShown(checked);
});

// Right side:
var checkbox1_right = ui.Checkbox('Tile Coverage', false);
checkbox1_right.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox1_right.onChange(function(checked) {
  // Shows or hides the map layer based on the checkbox's value.
  rightMap.layers().get(1).setShown(checked);
});
var checkbox2_right = ui.Checkbox('Tile Density', false);
checkbox2_right.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox2_right.onChange(function(checked) {
  rightMap.layers().get(2).setShown(checked);
});
var checkbox3_right = ui.Checkbox('DEM Coverage', false);
checkbox3_right.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
checkbox3_right.onChange(function(checked) {
  rightMap.layers().get(3).setShown(checked);
});

// Add title to the layer panel:
var layerboxTitle_l = ui.Label('Left Map');
  layerboxTitle_l.style().set('fontWeight', 'bold');
  layerboxTitle_l.style().set({fontSize:'12px',padding:'0px', textAlign:'left',backgroundColor:'rgba(255,255,255,0)'});
layerPanel_left.widgets().set(0,layerboxTitle_l);

var layerboxTitle_r = ui.Label('Right Map');
  layerboxTitle_r.style().set('fontWeight', 'bold');
  layerboxTitle_r.style().set({fontSize:'12px',padding:'0px', textAlign:'left',backgroundColor:'rgba(255,255,255,0)'});
layerPanel_right.widgets().set(0,layerboxTitle_r);

// Add checkboxes to the panels
var subPanelStyle = {backgroundColor:'rgba(255,255,255,0)'};

layerPanel_left.widgets().set(1,ui.Panel({
  widgets:[checkbox1_left,checkbox2_left,checkbox3_left],style: subPanelStyle}));

layerPanel_right.widgets().set(1,ui.Panel({
  widgets:[checkbox1_right,checkbox2_right,checkbox3_right],style: subPanelStyle}));


// Split map:
var splitPanel = ui.SplitPanel({
  firstPanel: leftMap,
  secondPanel: rightMap,
  orientation: 'horizontal',
  wipe: true,
  //style: {width: '1200px'}
  style: {stretch: 'both'}
});

// Link the two maps:
var linker = ui.Map.Linker([leftMap, rightMap]);
ui.root.widgets().reset([splitPanel]);

// Create a panel:
var panel = ui.Panel({
  layout: ui.Panel.Layout.flow('vertical'),
  style: {width: '350px'}
});

// Add the title
var appTitle = ui.Label('High-Res Land Cover Analysis of the Southern US Coast');
  appTitle.style().set('color', 'blue');
  appTitle.style().set('fontWeight', 'bold');
  appTitle.style().set({fontSize:'16px', padding:'10px', textAlign: 'center'});

//Add logo
var logo1 = ee.Image("users/lizcanosandoval/logos/USF-CMS-Logo");
var logo2 = ee.Image("users/lizcanosandoval/logos/TAMUCC_block-color");
var branding1 = ui.Thumbnail({
  image:logo1,
  params:{bands:['b1','b2','b3'],min:0,max:255},
  style:{width:'150px',height:'40px', padding: '0px 0px 0px 4px'}
});
var branding2 = ui.Thumbnail({
  image:logo2,
  params:{bands:['b1','b2','b3'],min:0,max:255},
  style:{width:'120px',height:'50px', padding: '0px 0px 0px 4px'}
});

// Add description
var appDesc = ui.Label('Application to visualize and compare land cover changes over the wetland areas of'+
    ' the Southern US coast produced with WorldView-2 and WorldView-3 imagery (2 m per pixel).'+
    ' This product has a temporal coverage from 2009 to 2018 (not consistent over time).'+
    ' App developed by the Institute for Marine Remote Sensing (IMARS) at the College of Marine Science, '+
    'University of South Florida.');
appDesc.style().set({fontSize:'13px', padding:'0px'});

var docum = ui.Label({
    value: 'See Documentation Here',
    style: {
    fontSize: '13px',
    padding:'0px 0px 0px 80px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
docum.setUrl('https://github.com/luislizcano/3D-wetlands-app');

var start = ui.Label('Quick Start: \n1. Click on one or more Counties of interest. \n2. Choose date ranges for two periods.'+
    '\n3. Generate a land cover mosaic and DEM. \n4. More features are enabled after creating a mosaic.'+
    '\n5. To reset the app click on the "Clear Selection" button \n in step 3 or press F5 to refresh the site.');
start.style().set({fontSize:'13px', padding:'0px', whiteSpace: 'pre'});
// Add widgets to panel
panel.widgets().set(0,appTitle); //Add title to panel
panel.widgets().set(1,ui.Panel([branding1,branding2],ui.Panel.Layout.flow('horizontal'))); //Add logo to panel
panel.widgets().set(2,appDesc); //Add description to panel
panel.widgets().set(3,docum); //Add documentation link
panel.widgets().set(4,start);

///// SIDEPANEL SETTINGS ///////

///// REGIONS SECTION /////
var titleRegion = ui.Label({
  value: '1. Region of Interest:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
var textRegion = ui.Label('Click on one or more Counties of interest.');
textRegion.style().set({fontSize:'13px', padding:'0px'});

// Add widgets to panel
panel.widgets().set(5,titleRegion);
panel.widgets().set(6,textRegion);

//// Functions to create a table of properties from selected features on map.
//// Most of this functions were modified from the 'Global Population Explorer APP':

// Empty variable for selecting points on map.
var selectedPoints = [];

// Returns the list of features the user has selected.
function getSelectedFeatures() {
  return regions.filterBounds(ee.Geometry.MultiPoint(selectedPoints));
}

// Makes a table of the given features by name.
function makeResultsTable(regions) {
  var table = ui.Chart.feature.byFeature(regions, '0_Country');
  table.setChartType('Table');
  table.setOptions({allowHtml: true, pageSize: 5, sortColumn: 1});
  table.style().set({stretch: 'both'});
  return table;
}

// Makes a bar chart of the given FeatureCollection of countries by name.
function makeResultsBarChart(regions) {
  //Filter image collection by area
  var filterCollection = wetlands.filterBounds(getSelectedFeatures());
  // Get a list of image dates in format YYYY-MM
  var dates = filterCollection
    .map(function(image) {
      return ee.Feature(null, {'date': image.date().format('YYYY-MM')});
    }).aggregate_array('date');
  //Get frequency histogram and get keys and values
  var hist = dates.reduce(ee.Reducer.frequencyHistogram());
  var keys = ee.Dictionary(hist).keys();
  var values = ee.Dictionary(hist).values();
  // Create Chart
  var chart = ui.Chart.array.values({
  array: values,
  axis: 0,
  xLabels: keys
  });
  // Set chart style properties.
  var chartStyle = {
    title: 'Available Images For The Selected Counties',
    hAxis: {
      title: 'Number of Images',
      titleTextStyle: {italic: false, bold: true},
      gridlines: {color: 'FFFFFF'},
    },
    vAxis: {
      title: 'Year-Month',
      titleTextStyle: {italic: false, bold: true},
      gridlines: {color: 'FFFFFF'},
      format: 'short',
      baselineColor: 'FFFFFF',
    },
    chartArea: {backgroundColor: 'EBEBEB'}
  };
  chart.setSeriesNames(['Images']);
  chart.setChartType('BarChart');
  chart.setOptions(chartStyle);
  chart.style().set({stretch: 'both'});
  return chart;
}

// Updates the map overlay using the currently-selected features.
function updateOverlay() {
  var overlay = getSelectedFeatures().style(highlight_STYLE);
  leftMap.layers().set(4, ui.Map.Layer(overlay,{},'Selected Region')); //Layer number 5
  rightMap.layers().set(4, ui.Map.Layer(overlay,{},'Selected Region'));//Layer number 5
}

// Updates the table using the currently-selected table function.
// This function was modified from the 'Global Population Explorer APP'
function updateTable() {
  var TableBuilder = chartTypeToggleButton.value;
  var table = TableBuilder(getSelectedFeatures());
  resultsPanel.clear().add(table);//.add(newbuttonTable);
  buttonTable.widgets().reset([newbuttonTable]);//buttonTable.clear().add(newbuttonTable)
}

// Register a click handler for the map that adds the clicked point to the
// list and updates the map overlay and table accordingly.
function handleMapClick(location) {
  selectedPoints.push([location.lon, location.lat]);
  updateOverlay();
  updateTable();
  }

// Add selection to map
leftMap.onClick(handleMapClick);
rightMap.onClick(handleMapClick);

// A button widget that toggles (or cycles) between states.
// To construct a ToggleButton, supply an array of objects describing
// the desired states, each with 'label' and 'value' properties.
// This function was modified from the 'Global Population Explorer APP'
function ToggleButton(states, onClick) {
  var index = 0;
  var button = ui.Button(states[index].label);
  button.value = states[index].value;
  button.onClick(function() {
    index = ++index % states.length;
    button.setLabel(states[index].label);
    button.value = states[index].value;
    onClick();
  });
  return button;
}

// Our chart type toggle button: the button text is the opposite of the
// current state, since you click the button to switch states.
// This function was modified from the 'Global Population Explorer APP'
var chartTypeToggleButton = ToggleButton(
    [{value:makeResultsTable,label:'Display number of images'},
    {value:makeResultsBarChart,label:'Display selected Counties'}], updateTable);

// Create an empty panel to be updated with table results.
var resultsPanel = ui.Panel();

// Empty panel to be replaced by a button with chart results
var buttonTable = ui.Panel();
var newbuttonTable = ui.Panel(
  [chartTypeToggleButton],
  ui.Panel.Layout.Flow('horizontal'), {margin: '0 0 0 auto', width: '500px'});

// Add widget panel to the master panel
panel.widgets().set(7,resultsPanel);//ui.Panel.Layout.flow('horizontal')
panel.widgets().set(8,buttonTable);

///// DATES SECTION - LEFT MAP/////
var textChoose = ui.Label({
  value: '2 Choose Date Ranges:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textLeftMap = ui.Label({
  value: 'Left Map:',
  style: {
    fontWeight: 'bold',
    fontSize: '13px',
    padding: '0px 0px 0px 8px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textStart = ui.Label({
  value: 'Start date:',
  style: {
    fontSize: '13px',
    padding: '0px 0px 0px 20px',
    stretch: 'horizontal',
    }
});

var startMonth = ui.Select({
  items: Object.keys(month),
  placeholder: 'Choose Month...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var startYear = ui.Select({
  items: year,
  placeholder: 'Choose Year...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var textEnd = ui.Label({
  value: 'End date:',
  style: {
    fontSize: '13px',
    padding: '0px 0px 0px 20px',
    stretch: 'horizontal',
    }
});

var endMonth = ui.Select({
  items: Object.keys(month),
  placeholder: 'Choose Month...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var endYear = ui.Select({
  items: year,
  placeholder: 'Choose Year...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

// Add widgets to panel
panel.widgets().set(9,ui.Panel([
  textChoose,
  textLeftMap],
  ui.Panel.Layout.flow('vertical')));
panel.widgets().set(10,ui.Panel([
  textStart,
  startMonth,
  startYear],
  ui.Panel.Layout.flow('horizontal')));
panel.widgets().set(11,ui.Panel([
  textEnd,
  endMonth,
  endYear],
  ui.Panel.Layout.flow('horizontal')));


///// DATES SECTION - RIGHT MAP/////
var textRightMap = ui.Label({
  value: 'Right Map:',
  style: {
    fontWeight: 'bold',
    fontSize: '13px',
    padding: '0px 0px 0px 8px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textStartR = ui.Label({
  value: 'Start date:',
  style: {
    fontSize: '13px',
    padding: '0px 0px 0px 20px',
    stretch: 'horizontal',
    }
});

var startMonthR = ui.Select({
  items: Object.keys(month),
  placeholder: 'Choose Month...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var startYearR = ui.Select({
  items: year,
  placeholder: 'Choose Year...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var textEndR = ui.Label({
  value: 'End date:',
  style: {
    fontSize: '13px',
    padding: '0px 0px 0px 20px',
    stretch: 'horizontal',
    }
});

var endMonthR = ui.Select({
  items: Object.keys(month),
  placeholder: 'Choose Month...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

var endYearR = ui.Select({
  items: year,
  placeholder: 'Choose Year...',
  style: {width: '35%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

// Add widgets to panel
panel.widgets().set(12,ui.Panel([
  textRightMap],
  ui.Panel.Layout.flow('vertical')));
panel.widgets().set(13,ui.Panel([
  textStartR,
  startMonthR,
  startYearR],
  ui.Panel.Layout.flow('horizontal')));
panel.widgets().set(14,ui.Panel([
  textEndR,
  endMonthR,
  endYearR],
  ui.Panel.Layout.flow('horizontal')));


///// GENERATE MOSAIC SECTION /////
var textMosaic = ui.Label({
  value: '3. Generate Land Cover Mosaic and DEM:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textPixel = ui.Label({
    value: 'Select either one or all classes to create the mosaic. Then hit the "Generate" button and wait a few seconds'+
      ' for the mosaic to load. The DEM associated to the selected area will show up in a new layer.'+
      ' Click on "Clear Selection" to clear outputs and select a new area of interest.',
    style: {
    fontSize: '13px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var classSelector = ui.Select({
  items: Object.keys(pixelClass),
  placeholder: 'Choose Class...',
  style: {width: '65%', stretch: 'horizontal',padding:'0px 0px 0px 100px'}
});


// Add widget to panel
panel.widgets().set(15,ui.Panel([
  textMosaic,
  textPixel,
  classSelector],
  ui.Panel.Layout.flow('vertical')));


//////////////////////////////////////////////////////////////////////////////////////
/////////////////////////////////////////////////////////////////////////////////////

// Function to create mosaics from selected regions and dates.
function doMosaic() {
  // Get start and end dates from button selections
  var startDate = startYear.getValue() + "-" + month[startMonth.getValue()][0];
  var endDate = endYear.getValue() + "-" + month[endMonth.getValue()][0];

  //Filter pixel values from the selector
  var pixelValue = ee.Number(pixelClass[classSelector.getValue()]);
  var maskPixels = function (image){
  var mask = ee.Image(image).eq(pixelValue);
    return image.updateMask(mask);
    };

  //Select pixels equal to 11-developed
  var developed = function (image){
    var mask = ee.Image(image).eq(11);
    return image.updateMask(mask);
  };

  //Create mask of only water
  var water = function (image){
    var mask = ee.Image(image).eq(3);
    return image.updateMask(mask);
  };

  // Filter the collection by dates and counties selected.
  var filterCollection = wetlands//.filterMetadata('system:index','not_contains','Cloudy')
                        .filterDate(startDate, endDate)
                        .filterBounds(getSelectedFeatures());

  // Function to clean missclassified pixels
  var cleanDeveloped = function(collection){
    // Clean misclassified cloudy pixels:
    var fullCollection = collection//.filterMetadata('system:index','not_contains','Cloudy')
                          .filterBounds(getSelectedFeatures());
    //Select only developed pixels
    var devCollection = fullCollection.map(developed);
    //Create mosaic suming pixel values
    var sumDeveloped = devCollection.sum();
    //Select pixels greater than 33 (presence of developed class in 3 or more images)
    var selectThreshold = sumDeveloped.gt(32);
    //Create a mask for misclassified pixels
    var justDeveloped = sumDeveloped.updateMask(selectThreshold);
    //Some areas over water bodies have cloudy pixels we can mask out
    var waterCollection = fullCollection.map(water);
    var waterMask = ee.ImageCollection(waterCollection).max().mask().not();
  return justDeveloped.updateMask(waterMask);
  }

  //Apply water mask on the cleaned collection. This is the mask for
  //"real" developed pixels.
  var realDeveloped = cleanDeveloped(wetlands)

  // Function to clean mosaic
  var cleanCollection = filterCollection.map(function (image){
    var developed = image.eq(11); //Developed
    var imageUpdated = image.updateMask(developed); //Developed mask
    var falseImg = realDeveloped.mask().not();
    var maskDev = imageUpdated.updateMask(falseImg).mask().not();
    var imageMask = image.updateMask(maskDev);
    return imageMask;
  })

  // Select the pixel value if one class is selected
  var condition = ee.Algorithms.If({
    condition: pixelValue.neq(0),
    trueCase: ee.ImageCollection(filterCollection.map(maskPixels)),
    falseCase: ee.ImageCollection(cleanCollection)
   });

  // Create mosaic - LEFT
  var mosaicImage = ee.ImageCollection(condition).max().clip(getSelectedFeatures());

  // Palette color codes
  var palette = [
  "#8C8C8C",       // 0 no data
  "#FFFFFF",       // 1 cloud
  "#621E01",       // 2 soil
  "#1F59CC",       // 3 water
  "FF00FF",        // 4 - unused
  "#E2D924",       // 5 dead grass
  "#7CCD11",       // 6 marsh
  "#AD6309",       // 7 scrub
  "#27D310",       // 8 grass
  "106F00",       // 9 forested upland
  "1EE682",       // 10 forested wetland
  "1E1E1E",       // 11 developed
  ];


  // Clip DEM by counties selected:
  // Filter the collection by dates and counties selected.
  var filterDEM = dem.filterBounds(getSelectedFeatures());
  var clipDEM = filterDEM.mosaic().clip(getSelectedFeatures()).rename('dem');

  // Find min-max values of the DEM region:
  var rangeDem = clipDEM.reduceRegion({reducer:ee.Reducer.percentile([1,50,99]),geometry:getSelectedFeatures(),scale:100,bestEffort:true});

  // Dictionary with values to use in a Server side function using evaluate() ahead.
  var minMax = ee.Dictionary({
    per1: rangeDem.getNumber('dem_p1'),
    per99: rangeDem.getNumber('dem_p99'),
    per50: rangeDem.getNumber('dem_p50')
  });

  var dem_palette = ['030d81','0519ff','05e8ff','11ff01','fbff01','ff9901','ff0000','ad0000'];

  //Add DEM and Mosaic to map
  minMax.evaluate(function(dict) {
    var dem_vis = {
      min: dict.per1,
      max: dict.per99,
      palette: dem_palette
    };
    leftMap.addLayer(clipDEM, dem_vis,'DEM',false); // (Layer #6)
  });
  leftMap.addLayer(mosaicImage, {min:0, max:11, palette: palette},'Left LC Mosaic'); // (Layer #7)

  //Add layers to checkbox
  var checkbox4_left = ui.Checkbox('DEM', false);
  checkbox4_left.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
  checkbox4_left.onChange(function(checked) {
    leftMap.layers().get(6).setShown(checked);
  });
  var checkbox5_left = ui.Checkbox('Left LC Mosaic', true);
  checkbox5_left.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
  checkbox5_left.onChange(function(checked) {
    leftMap.layers().get(5).setShown(checked);
  });

  layerPanel_left.widgets().set(2,ui.Panel({
    widgets:[checkbox4_left,checkbox5_left],style: subPanelStyle}));

  // Additionally, show the number of images used to create current mosaic
  var count = filterCollection.size();
  count.evaluate(function(result){
    countLabel = ui.Label('Images used for left mosaic: '+ result, {fontSize: '13px', padding:'0px 0px 0px 20px'});
    countImages.widgets().reset([countLabel]);
      });

  //////////////////
  //Right Mosaic: //
  //////////////////
  // Get start and end dates from button selections
  var startDateR = startYearR.getValue() + "-" + month[startMonthR.getValue()][0];
  var endDateR = endYearR.getValue() + "-" + month[endMonthR.getValue()][0];

  // Filter the collection by dates selected.
  var filterCollectionR = wetlands//.filterMetadata('system:index','not_contains','Cloudy')
                        .filterDate(startDateR, endDateR)
                        .filterBounds(getSelectedFeatures());

  // Function to clean mosaic
  var cleanCollectionR = filterCollectionR.map(function (image){
    var developed = image.eq(11); //Developed
    var imageUpdated = image.updateMask(developed); //Developed mask
    var falseImg = realDeveloped.mask().not();
    var maskDev = imageUpdated.updateMask(falseImg).mask().not();
    var imageMask = image.updateMask(maskDev);
    return imageMask;
  });

  // Select the pixel value if one class is selected
  var conditionR = ee.Algorithms.If({
    condition: pixelValue.neq(0),
    trueCase: ee.ImageCollection(filterCollectionR.map(maskPixels)),
    falseCase: ee.ImageCollection(cleanCollectionR)
   });

  // Create mosaic
  var mosaicImageR = ee.ImageCollection(conditionR).max().clip(getSelectedFeatures());

  //Add mosaic to map
  minMax.evaluate(function(dict) {
    var dem_vis = {
      min: dict.per1,
      max: dict.per99,
      palette: dem_palette
    };
    rightMap.addLayer(clipDEM, dem_vis,'DEM',false); // (Layer #6)
  });
  rightMap.addLayer(mosaicImageR, {min:0, max:11, palette: palette},'Right LC Mosaic'); // (Layer #7)

  //Add layers to checkbox
  var checkbox4_right = ui.Checkbox('DEM', false);
  checkbox4_right.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
  checkbox4_right.onChange(function(checked) {
    rightMap.layers().get(6).setShown(checked);
  });
  var checkbox5_right = ui.Checkbox('Right LC Mosaic', true);
  checkbox5_right.style().set({fontSize: '11px',backgroundColor: 'rgba(255, 255, 255, 0)'});
  checkbox5_right.onChange(function(checked) {
    rightMap.layers().get(5).setShown(checked);
  });

  layerPanel_right.widgets().set(2,ui.Panel({
    widgets:[checkbox4_right,checkbox5_right],style: subPanelStyle}));

  // Additionally, show the number of images used to create current mosaic
  var countR = filterCollectionR.size();
  countR.evaluate(function(result){
    countLabel = ui.Label('Images used for right mosaic: '+ result, {fontSize: '13px', padding:'0px 0px 0px 20px'});
    countImagesR.widgets().reset([countLabel]);
      });

  //// GRADIENT BAR FOR DEM
  // Creates a color bar thumbnail image for use in legend from the given color
  // palette.
  minMax.evaluate(function(dict) {
    var dem_vis = {
      min: dict.per1,
      max: dict.per99,
      palette: dem_palette
    };
    function makeColorBarParams(colorPalette) {
      return {
        bbox: [0, 0, 1, 0.1],
        dimensions: '50x5',
        format: 'png',
        min: 0,
        max: 1,
        palette: colorPalette,
      };
    }

    // Create the color bar for the legend.
    var colorBar = ui.Thumbnail({
      image: ee.Image.pixelLonLat().select(0),
      params: makeColorBarParams(dem_palette),
      style: {stretch: 'horizontal', margin: '0px 8px', maxHeight: '24px'},
    });

    // Create a panel with three numbers for the legend.
    var legendLabels = ui.Panel({
      widgets: [
        ui.Label(dict.per1.toFixed(1), {margin: '4px 8px'}),
        ui.Label(
            (dict.per99.toFixed(1)/2),
            {margin: '4px 8px', textAlign: 'center', stretch: 'horizontal'}),
        ui.Label(dict.per99.toFixed(1), {margin: '4px 8px'})
      ],
      layout: ui.Panel.Layout.flow('horizontal')
    });

    var legendTitle = ui.Label({
      value: 'Elevation (m):',
      style: {fontWeight: 'bold',fontSize:'12px'}
    });

    // Add the legendPanel to the map.
    var legendPanel = ui.Panel({widgets:[legendTitle, colorBar, legendLabels]});
    subPaneldem.add(legendPanel);
  })


  //Settings for downloading mosaics
  var geometry = ee.Geometry(getSelectedFeatures().geometry(10)).bounds();

  var url = mosaicImage.getThumbURL({
    'dimensions': 1000,
    'min': 0,
    'max': 11,
    'palette': palette,
    'region': geometry,
    'crs': 'EPSG:3857'
  });
  var urlR = mosaicImageR.getThumbURL({
    'dimensions': 1000,
    'min': 0,
    'max': 11,
    'palette': palette,
    'region': geometry,
    'crs': 'EPSG:3857'
  });
  minMax.evaluate(function(dict) {
    var urlDEM = clipDEM.getThumbURL({
      'dimensions': 1000,
      'min': dict.per1,
      'max': dict.per99,
      'palette': dem_palette,
      'region': geometry,
      'crs': 'EPSG:3857'
    });
  downloadTextDEM.setUrl(urlDEM);
  downloadTextDEM.style().set({shown: true});
  });
  downloadText.setUrl(url);
  downloadTextR.setUrl(urlR);

  //Make items visible.
  chartDesc.style().set({shown: true});
  textChart.style().set({shown: true});
  chartButton.style().set({shown: true});
  chartButton2.style().set({shown: true});
  textDownload.style().set({shown: true});
  textDownloadInfo.style().set({shown: true});
  downloadText.style().set({shown: true});
  downloadTextR.style().set({shown: true});

  /// Profile Chart Settings
  var dem_repr = clipDEM.reproject({
      crs: 'EPSG:4326',
      scale: 2
    });
  //Reproject mosaic and remap pixel values
  var from = [0,1,2,3,5,6,7,8,9,10,11];
  var to = [0,1,2,3,4,5,6,7,8,9,10];
  var mosaicL_repr = mosaicImage.reproject({
      crs: 'EPSG:4326',
      scale: 2
    }).remap(from,to);
  var mosaicR_repr = mosaicImageR.reproject({
      crs: 'EPSG:4326',
      scale: 2
    }).remap(from,to);
  //Concatenate images and convert to bands.
  concatenated = ee.ImageCollection([dem_repr,mosaicL_repr]).toBands().toFloat();
  concatenated2 = ee.ImageCollection([dem_repr,mosaicR_repr]).toBands().toFloat();
  //print(concatenated)

  //Show class palette in Panel.
  panel.widgets().get(17).style().set({shown: true});

  leftMap.centerObject(geometry,9)
}


// Add mosaic button
var mosaicButton = ui.Button({
  label: 'Generate', style: {width: '45%', stretch: 'horizontal',padding:'0px 0px 0px 10px'}
});

// Add function to the mosaic button
mosaicButton.onClick(doMosaic);

// Clears the set of selected points and resets the overlay and results
// panel to their default state.
function clearResults() {
  selectedPoints = [];
  mosaicButton = [];
  //Remove layers
  leftMap.layers().remove(leftMap.layers().get(6)); //It removes the layer #7 (Mosaic layer)
  leftMap.layers().remove(leftMap.layers().get(5)); //It removes the layer #6 (DEM layer)
  leftMap.layers().remove(leftMap.layers().get(4)); //It removes the layer #5 (Selected features)
  rightMap.layers().remove(leftMap.layers().get(6)); //It removes the layer #7 (Mosaic layer)
  rightMap.layers().remove(rightMap.layers().get(5)); //It removes the layer #6 (DEM layer)
  rightMap.layers().remove(rightMap.layers().get(4)); //It removes the layer #5 (Selected features)
  //Remove checkboxes
  layerPanel_left.widgets().remove(layerPanel_left.widgets().get(2)); //Removes checkboxes
  layerPanel_right.widgets().remove(layerPanel_right.widgets().get(2)); //Removes checkboxes
  //Reset Image Counters
  var clearLabel = ui.Label('Cleared!', {fontSize: '13px', padding:'0px 0px 0px 20px'});
  var clearLabelR = ui.Label('', {fontSize: '13px', padding:'0px 0px 0px 20px'});
  countImages.widgets().reset([clearLabel]); //Reset Number of Images Widget
  countImagesR.widgets().reset([clearLabelR]); //Reset Number of Images Widget
  //Reset DEM Bar Gradient
  var reset_subPanel = ui.Panel();
  subPaneldem.widgets().reset([reset_subPanel]);
  //Reset Selection Table Results
  var reset_buttonTable = ui.Panel();
  var reset_resultsPanel = ui.Panel();
  buttonTable.widgets().reset([reset_buttonTable]);
  resultsPanel.widgets().reset([reset_resultsPanel]);
  //Reset Chart Button and others:
  concatenated = ee.Image(); //For first chart
  var reset_subPanel2a = ui.Panel();
  subPanelChart.widgets().reset([reset_subPanel2a]);
  concatenated2 = ee.Image(); //For second chart
  var reset_subPanel2b = ui.Panel();
  subPanelChart2.widgets().reset([reset_subPanel2b]);
  //Hide items again.
  chartDesc.style().set({shown: false});
  textChart.style().set({shown: false});
  chartButton.style().set({shown: false});
  chartButton2.style().set({shown: false});
  textDownload.style().set({shown: false});
  textDownloadInfo.style().set({shown: false});
  downloadText.style().set({shown: false});
  downloadTextR.style().set({shown: false});
  downloadTextDEM.style().set({shown: false});
  //Hide class palette
  panel.widgets().get(17).style().set({shown: false});
}

// A panel containing the two buttons, including the clearResults function.
var buttonPanel = ui.Panel(
    [mosaicButton,
    ui.Button('Clear Selection', clearResults, false,
    {width:'45%',stretch:'horizontal',padding:'0px 0px 0px 10px',color: 'red'})],
    ui.Panel.Layout.Flow('horizontal'));


// Add widget to panel
panel.widgets().set(16,buttonPanel);

//clearResults();

// Function to add classes palette in panel:
var add_legend2 = function(title, lbl, pal, lbl2, pal2) {
   var legend = ui.Panel({style: {position: 'bottom-right'}}), entry;
   legend.add(ui.Label({value: title, style: {fontWeight: 'bold', fontSize: '12px', margin: '0px 0px 4px 8px', padding: '0px' } }));
   for (var x = 0; x < lbl.length; x++){
     entry = [ ui.Label({style:{fontSize: '10px', color: pal[x], margin: '0 0 4px 8px'}, value: '██'}),
       ui.Label({value: labels[x], style: {fontSize: '10px', margin: '0px 0px 4px 4px',backgroundColor: '#f3f3f3'}})];
     legend.add(ui.Panel(entry, ui.Panel.Layout.Flow('horizontal'),{backgroundColor: '#f3f3f3'}));
   }
   var legend2 = ui.Panel({style: {position: 'bottom-right'}}), entry2;
   legend2.add(ui.Label({value: '', style: {fontWeight: 'bold', fontSize: '12px', margin: '14px 0px 4px 8px', padding: '0px' } }));
   for (var y = 0; y < lbl2.length; y++){
     entry2 = [ ui.Label({style:{fontSize: '10px', color: pal2[y], margin: '0 0 4px 8px'}, value: '██'}),
       ui.Label({value: labels2[y], style: {fontSize: '10px', margin: '0px 0px 4px 4px',backgroundColor: '#f3f3f3'}})];
     legend2.add(ui.Panel(entry2, ui.Panel.Layout.Flow('horizontal'),{backgroundColor: '#f3f3f3'}));
   }
    // Put both legends in the same panel:
    panel.widgets().set(17,ui.Panel([legend,legend2],ui.Panel.Layout.Flow('horizontal'),{padding:'0px 0px 0px 60px'})); };
   //rightMap.add(legend); };

// First part of the legend:
var labels = ['01 Cloud','02 Soil','03 Water','04 Dead grass','05 Marsh'];
var lg_palette = ['FFFFFF','621E01','1F59CC','E2D924','7CCD11'];
// Second part of the legend:
var labels2 = ['06 Scrub','07 Grass','08 Forested Upland','09 Forested Wetland','10 Developed'];
var lg_palette2 = ['AD6309','27D310','106F00','1EE682','1E1E1E'];

// Run function to add legend in panel:
add_legend2('Classes:', labels, lg_palette, labels2, lg_palette2);
panel.widgets().get(17).style().set({shown: false});
//print(panel.getLayout(17))

// Create sub-panel to allocate the number of images used to create a mosaic,
// and add it to the master panel.
var countImages = ui.Panel();
var countImagesR = ui.Panel();
var countLabel = ui.Label();
var countLabelR = ui.Label();
countImages.add(countLabel);
countImagesR.add(countLabelR);
panel.widgets().set(18,countImages);
panel.widgets().set(19,countImagesR);

// Create sub-panel to allocate the DEM color bar,
// and add it to the master panel.
var subPaneldem = ui.Panel();
panel.widgets().set(20,subPaneldem);



//////  4. PROFILE CHART
/// Get generated DEM
var concatenated = ee.Image();
var concatenated2 = ee.Image();

/// Drawing transect functions (LEFT MAP)
var drawingTools = leftMap.drawingTools();
drawingTools.setShown(false);

var dummyGeometry = ui.Map.GeometryLayer({geometries: null, name: 'geometry', color: 'e00000'});
drawingTools.layers().add(dummyGeometry);

function clearGeometry() {
  var layers = drawingTools.layers();
  layers.get(0).geometries().remove(layers.get(0).geometries().get(0));
}

function drawLine() {
  clearGeometry();
  drawingTools.setShape('line');
  drawingTools.draw();
}

function createChart() {
  // Make the chart panel visible the first time a geometry is drawn.
  //if (!chartPanel.style().get('shown')) {
  //  chartPanel.style().set('shown', true);
  //}

  // Get the drawn geometry; it will define the reduction region.
  var aoi = drawingTools.layers().get(0).getEeObject();

  // Set the drawing mode back to null; turns drawing off.
  drawingTools.setShape(null);

  function sampleLinePoints(line, count) {
    var length = line.length();
    var step = line.length().divide(count);
    var distances = ee.List.sequence(0, length, step);

    function makePointFeature(coord, offset) {
      var pt = ee.Algorithms.GeometryConstructors.Point(coord);
      return new ee.Feature(pt).set('offset', offset);
    }

    var lines = line.cutLines(distances).geometries();

    var points =   lines.zip(distances).map(function(s) {
      var line = ee.List(s).get(0);
      var offset = ee.List(s).get(1);
      return makePointFeature(ee.Geometry(line).coordinates().get(0), offset);
    });

    points = points.add(makePointFeature(line.coordinates().get(-1), length));

    return new ee.FeatureCollection(points);
  }

  function getScale(image) {
    return image.projection().nominalScale().divide(ee.Projection('EPSG:4326').nominalScale());
  }

  function createProfileChart(image, line) {
    var scale = getScale(image);
    var segmentCount = aoi.length(1, 'EPSG:4326').divide(scale.multiply(28));//Pixel size 1.94 * 25.77 = 50m interval
    var points = sampleLinePoints(line, segmentCount);
    var samples = image.reduceRegions(points, ee.Reducer.first());
    var chart = ui.Chart.feature.byFeature(samples, 'offset');
    // Set chart style properties.
    var chartStyle = {
      title: 'Profile Chart: Left Map',
      series: {
        0: {targetAxisIndex: 0, type: 'line', color: '1d6b99'},
        1: {
          targetAxisIndex: 1,
          type: 'line',
          lineWidth: 0,
          pointSize: 1,
          color: 'e37d05'
          }
      },
      hAxis: {
        title: 'Transect length (m)',
        titleTextStyle: {italic: false, bold: true},
        gridlines: {color: 'FFFFFF'},
        viewWindow: {min: 0}
      },
      vAxes: {
        0: {
          title: 'Elevation (m)',
          titleTextStyle: {italic: false, bold: true},
          gridlines: {color: 'FFFFFF'},
          format: 'short',
          baselineColor: 'FFFFFF',
        },
        1: {
          title: 'Land Cover Class',
          titleTextStyle: {italic: false, bold: true},
          gridlines: {color: 'FFFFFF'},
          format: 'short',
          baselineColor: 'FFFFFF',
        }
      },
      chartArea: {backgroundColor: 'EBEBEB'},
      explorer: {}
    };
    chart.setSeriesNames(['Elevation','Land Cover Class']);
    chart.setOptions(chartStyle);
    //chart.style().set({stretch: 'both'});
    return chart;
  }

  var profileChart = createProfileChart(concatenated,aoi);

  // Replace the existing chart in the chart panel with the new chart.
  subPanelChart.widgets().reset([profileChart]);
}

drawingTools.onDraw(ui.util.debounce(createChart, 500));
drawingTools.onEdit(ui.util.debounce(createChart, 500));


/// Drawing transect functions (RIGHT MAP)
var drawingTools2 = rightMap.drawingTools();
drawingTools2.setShown(false);

var dummyGeometry2 = ui.Map.GeometryLayer({geometries: null, name: 'geometry', color: 'e00000'});
drawingTools2.layers().add(dummyGeometry2);

function clearGeometry2() {
  var layers = drawingTools2.layers();
  layers.get(0).geometries().remove(layers.get(0).geometries().get(0));
}

function drawLine2() {
  clearGeometry2();
  drawingTools2.setShape('line');
  drawingTools2.draw();
}

function createChart2() {
  // Get the drawn geometry; it will define the reduction region.
  var aoi = drawingTools2.layers().get(0).getEeObject();

  // Set the drawing mode back to null; turns drawing off.
  drawingTools2.setShape(null);

  function sampleLinePoints(line, count) {
    var length = line.length();
    var step = line.length().divide(count);
    var distances = ee.List.sequence(0, length, step);

    function makePointFeature(coord, offset) {
      var pt = ee.Algorithms.GeometryConstructors.Point(coord);
      return new ee.Feature(pt).set('offset', offset);
    }

    var lines = line.cutLines(distances).geometries();

    var points =   lines.zip(distances).map(function(s) {
      var line = ee.List(s).get(0);
      var offset = ee.List(s).get(1);
      return makePointFeature(ee.Geometry(line).coordinates().get(0), offset);
    });

    points = points.add(makePointFeature(line.coordinates().get(-1), length));

    return new ee.FeatureCollection(points);
  }

  function getScale(image) {
    return image.projection().nominalScale().divide(ee.Projection('EPSG:4326').nominalScale());
  }

  function createProfileChart2(image, line) {
    var scale = getScale(image);
    var segmentCount = aoi.length(1, 'EPSG:4326').divide(scale.multiply(28));//Pixel size 1.94 * 25.77 = 50m interval
    var points = sampleLinePoints(line, segmentCount);
    var samples = image.reduceRegions(points, ee.Reducer.first());
    var chart = ui.Chart.feature.byFeature(samples, 'offset');
    // Set chart style properties.
    var chartStyle = {
      title: 'Profile Chart: Right Map',
      series: {
        0: {targetAxisIndex: 0, type: 'line', color: '1d6b99'},
        1: {
          targetAxisIndex: 1,
          type: 'line',
          lineWidth: 0,
          pointSize: 1,
          color: 'e37d05'
          }
      },
      hAxis: {
        title: 'Transect length (m)',
        titleTextStyle: {italic: false, bold: true},
        gridlines: {color: 'FFFFFF'},
        viewWindow: {min: 0}
      },
      vAxes: {
        0: {
          title: 'Elevation (m)',
          titleTextStyle: {italic: false, bold: true},
          gridlines: {color: 'FFFFFF'},
          format: 'short',
          baselineColor: 'FFFFFF',
        },
        1: {
          title: 'Land Cover Class',
          titleTextStyle: {italic: false, bold: true},
          gridlines: {color: 'FFFFFF'},
          format: 'short',
          baselineColor: 'FFFFFF',
        }
      },
      chartArea: {backgroundColor: 'EBEBEB'},
      explorer: {}
    };
    chart.setSeriesNames(['Elevation','Land Cover Class']);
    chart.setOptions(chartStyle);
    //chart.style().set({stretch: 'both'});
    return chart;
  }

  var profileChart2 = createProfileChart2(concatenated2,aoi);

  // Replace the existing chart in the chart panel with the new chart.
  subPanelChart2.widgets().reset([profileChart2]);
}

drawingTools2.onDraw(ui.util.debounce(createChart2, 500));
drawingTools2.onEdit(ui.util.debounce(createChart2, 500));



var chartDesc = ui.Label({
  value: '4. Profile Chart:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textChart = ui.Label({
    value: 'Click on the respective button to draw a transect on the map and wait for profile chart to render.'+
      ' Click button again to draw a new transect.',
    style: {
    fontSize: '13px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
var chartButton = ui.Button({
  label: 'ꟷꟷ Left Map',
  onClick: drawLine,
  style: {padding:'0px 0px 0px 60px'}
});
var chartButton2 = ui.Button({
  label: 'ꟷꟷ Right Map',
  onClick: drawLine2,
  style: {padding:'0px 0px 0px 10px'}
});

//Hide items
chartDesc.style().set({shown: false});
textChart.style().set({shown: false});
chartButton.style().set({shown: false});
chartButton2.style().set({shown: false});

// Add widgets to Panel
panel.widgets().set(21,ui.Panel([
  chartDesc,
  textChart],
  ui.Panel.Layout.flow('vertical')));
panel.widgets().set(22,ui.Panel([
  chartButton,chartButton2],
  ui.Panel.Layout.flow('horizontal')));
//panel.widgets().set(23,ui.Panel([
//  chartButton2],
//  ui.Panel.Layout.flow('horizontal')));

// Create sub-panel to allocate the profile chart,
// and add it to the master panel.
var subPanelChart = ui.Panel(); //Profile Chart Left Map
var subPanelChart2 = ui.Panel(); //Profile Chart Right Map
panel.widgets().set(24,subPanelChart);
panel.widgets().set(25,subPanelChart2);


///// DOWNLOAD MOSAIC SECTION /////

var textDownload = ui.Label({
  value: '5. Download Land Cover Mosaics and DEM (.png):',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
var textDownloadInfo = ui.Label({
    value: 'Download mosaics in png format. Max resolution is 1000x1000 pixels. The image may take some seconds/minutes'+
      ' to show up and download. Warning: There is risk of exceeding the Earth Engine capacity if the mosaic is too large, so'+
      ' it is recommended to work with one (or a few) counties at a time if you want to download images.',
    style: {
    fontSize: '13px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

// Download button
var downloadText = ui.Label({
  value: 'Left Map', style: {padding:'0px 0px 0px 20px'}
});
var downloadTextR = ui.Label({
  value: 'Right Map', style: {padding:'0px 0px 0px 20px'}
});
var downloadTextDEM = ui.Label({
  value: 'DEM', style: {padding:'0px 0px 0px 20px'}
});

//Hide items
textDownload.style().set({shown: false});
textDownloadInfo.style().set({shown: false});
downloadText.style().set({shown: false});
downloadTextR.style().set({shown: false});
downloadTextDEM.style().set({shown: false});

// Add widgets to panel
panel.widgets().set(26,ui.Panel([
  textDownload,
  textDownloadInfo],
  ui.Panel.Layout.flow('vertical')));
panel.widgets().set(27,ui.Panel([
  downloadText,
  downloadTextR,
  downloadTextDEM],
  ui.Panel.Layout.flow('horizontal')));



///// ADVANCED INTERFACE /////

var linkDesc = ui.Label({
  value: 'For Earth Engine Users:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var textLinkInfo = ui.Label({
    value: 'If you have a GEE account, you can use the'+
      ' advanced interface of this App, which enables complete access to the image'+
      ' collection, download of mosaics and area calculations.',
    style: {
    fontSize: '13px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

var Link = ui.Label({
    value: 'Advanced Interface',
    style: {
    fontSize: '13px',
    padding:'0px 0px 0px 80px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
Link.setUrl('https://code.earthengine.google.com/08cca563bf9fc4cce30f3f8d3cff00e2');

panel.widgets().set(28,ui.Panel([
  linkDesc,
  textLinkInfo,
  Link],
  ui.Panel.Layout.flow('vertical')));

////// FINAL INFORMATION //////////
var textFinal = ui.Label({
  value: 'More Information:',
  style: {
    fontWeight: 'bold',
    fontSize: '15px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});
var textFinalInfo = ui.Label({
    value: 'If you are interested in our work or want to provide feedback,'+
      ' please contact Dr. Frank Muller-Karger (carib@usf.edu) or Luis Lizcano-Sandoval (luislizcanos@usf.edu).',
    style: {
    fontSize: '13px',
    padding: '0px',
    stretch: 'horizontal',
    textAlign: 'left'}
});

panel.widgets().set(29,ui.Panel([
  textFinal,
  textFinalInfo],
  ui.Panel.Layout.flow('vertical')));

ui.root.insert(0, panel);
