1.正常使用

在Lua使用的形式和C#中大致相同，只是Lua使用表的形式来模拟V3类型,原来C#中各种常用的属性和方法也都相应的被实现了。（详情可查看文末源码）

使用示例：

 local V3;
 V3 = Vector3(0,0,0);
 V3 = Vector3.zero;
 V3 = Vector3.left * 10;
 V3 = Vector3.left * 10 + Vector3.down * 10;






1

2

3

4

5


2.遇到问题

当将一个number类型放到乘号左边时，则程序执行到这一行就不会向下执行了；【思考一下】

V3 = 10 * Vector3.left;






1


原来在C#中是没有这种限制的，想下面这种代码随便怎么放位置都可以，只要满足你的需求，写法随便；

V3 = (hang - 1) / 2 * Vector3.down * hangGao;

V3 =  Vector3.down * hangGao* (hang - 1) / 2;






1

2

3


但是在Lua中就只能将模拟 V3类型的变量放到前面来写；

3.原来如此

后知后觉：在Lua中V3是个表，而这个表的加，减，乘，除 这写运算操作试Lua使用原方法帮我们实现的，打开源码：

V3表乘法操作部分：

Vector3.__mul = function(va, d)
	if type(d) == "number" then
		return _new(va.x * d, va.y * d, va.z * d)
	else
		local vec = va:Clone()
		vec:MulQuat(d)
		return vec
	end
end






1

2

3

4

5

6

7

8

9


这下明白了吧，这个原方法定义的时候，第一个参数是模拟V3类型，第二个是参数是Number类型；所有就会有上面的问题，当我们将V3类型的变量放到后面写的时候，当然执行不下去了。

结论：使用V3变量时，放到表达式的最左侧书写

4.ToLua中的V3实现表

local math  = math
local acos	= math.acos
local sqrt 	= math.sqrt
local max 	= math.max
local min 	= math.min
local clamp = Mathf.Clamp
local cos	= math.cos
local sin	= math.sin
local abs	= math.abs
local sign	= Mathf.Sign
local setmetatable = setmetatable
local rawset = rawset
local rawget = rawget
local type = type

local rad2Deg = 57.295779513082
local deg2Rad = 0.017453292519943

local Vector3 = {}
local get = tolua.initget(Vector3)

Vector3.__index = function(t,k)
	local var = rawget(Vector3, k) if var == nil then var = rawget(get, k) if var ~= nil then return var(t) end end return var
end

function Vector3.New(x, y, z) local t = {x = x or 0, y = y or 0, z = z or 0}
	setmetatable(t, Vector3) return t
end

local _new = Vector3.New

Vector3.__call = function(t,x,y,z)
	local t = {x = x or 0, y = y or 0, z = z or 0}
	setmetatable(t, Vector3) return t
end

function Vector3:Set(x,y,z)
	self.x = x or 0
	self.y = y or 0
	self.z = z or 0
end

function Vector3.Get(v) return v.x, v.y, v.z
end

function Vector3:Clone()
	return setmetatable({x = self.x, y = self.y, z = self.z}, Vector3)
end

function Vector3.Distance(va, vb)
	return sqrt((va.x - vb.x)^2 + (va.y - vb.y)^2 + (va.z - vb.z)^2)
end

function Vector3.Dot(lhs, rhs)
	return lhs.x * rhs.x + lhs.y * rhs.y + lhs.z * rhs.z
end

function Vector3.Lerp(from, to, t)
	t = clamp(t, 0, 1)
	return _new(from.x + (to.x - from.x) * t, from.y + (to.y - from.y) * t, from.z + (to.z - from.z) * t)
end

function Vector3:Magnitude()
	return sqrt(self.x * self.x + self.y * self.y + self.z * self.z)
end

function Vector3.Max(lhs, rhs)
	return _new(max(lhs.x, rhs.x), max(lhs.y, rhs.y), max(lhs.z, rhs.z))
end

function Vector3.Min(lhs, rhs)
	return _new(min(lhs.x, rhs.x), min(lhs.y, rhs.y), min(lhs.z, rhs.z))
end

function Vector3.Normalize(v)
	local x,y,z = v.x, v.y, v.z local num = sqrt(x * x + y * y + z * z) if num > 1e-5 then return setmetatable({x = x / num, y = y / num, z = z / num}, Vector3) end return setmetatable({x = 0, y = 0, z = 0}, Vector3)
end

function Vector3:SetNormalize()
	local num = sqrt(self.x * self.x + self.y * self.y + self.z * self.z) if num > 1e-5 then self.x = self.x / num
		self.y = self.y / num
		self.z = self.z /num else self.x = 0
		self.y = 0
		self.z = 0
	end return self
end

function Vector3:SqrMagnitude()
	return self.x * self.x + self.y * self.y + self.z * self.z
end

local dot = Vector3.Dot

function Vector3.Angle(from, to)
	return acos(clamp(dot(from:Normalize(), to:Normalize()), -1, 1)) * rad2Deg
end

function Vector3:ClampMagnitude(maxLength)
	if self:SqrMagnitude() > (maxLength * maxLength) then self:SetNormalize()
		self:Mul(maxLength) end return self
end


function Vector3.OrthoNormalize(va, vb, vc)
	va:SetNormalize()
	vb:Sub(vb:Project(va))
	vb:SetNormalize() if vc == nil then
		return va, vb
	end vc:Sub(vc:Project(va))
	vc:Sub(vc:Project(vb))
	vc:SetNormalize() return va, vb, vc
end

function Vector3.MoveTowards(current, target, maxDistanceDelta)
	local delta = target - current local sqrDelta = delta:SqrMagnitude()
	local sqrDistance = maxDistanceDelta * maxDistanceDelta if sqrDelta > sqrDistance then local magnitude = sqrt(sqrDelta) if magnitude > 1e-6 then delta:Mul(maxDistanceDelta / magnitude) delta:Add(current) return delta
		else return current:Clone()
		end end return target:Clone()
end

function ClampedMove(lhs, rhs, clampedDelta)
	local delta = rhs - lhs if delta > 0 then
		return lhs + min(delta, clampedDelta)
	else
		return lhs - min(-delta, clampedDelta)
	end
end

local overSqrt2 = 0.7071067811865475244008443621048490

local function OrthoNormalVector(vec)
	local res = _new() if abs(vec.z) > overSqrt2 then local a = vec.y * vec.y + vec.z * vec.z
		local k = 1 / sqrt (a)
		res.x = 0
		res.y = -vec.z * k
		res.z = vec.y * k
	else local a = vec.x * vec.x + vec.y * vec.y
		local k = 1 / sqrt (a)
		res.x = -vec.y * k
		res.y = vec.x * k
		res.z = 0
	end return res
end

function Vector3.RotateTowards(current, target, maxRadiansDelta, maxMagnitudeDelta)
	local len1 = current:Magnitude()
	local len2 = target:Magnitude() if len1 > 1e-6 and len2 > 1e-6 then local from = current / len1
		local to = target / len2 local cosom = dot(from, to) if cosom > 1 - 1e-6 then return Vector3.MoveTowards (current, target, maxMagnitudeDelta) elseif cosom < -1 + 1e-6 then local axis = OrthoNormalVector(from) local q = Quaternion.AngleAxis(maxRadiansDelta * rad2Deg, axis) local rotated = q:MulVec3(from) local delta = ClampedMove(len1, len2, maxMagnitudeDelta) rotated:Mul(delta) return rotated
		else local angle = acos(cosom) local axis = Vector3.Cross(from, to) axis:SetNormalize () local q = Quaternion.AngleAxis(min(maxRadiansDelta, angle) * rad2Deg, axis) local rotated = q:MulVec3(from) local delta = ClampedMove(len1, len2, maxMagnitudeDelta) rotated:Mul(delta) return rotated
		end
	end return Vector3.MoveTowards(current, target, maxMagnitudeDelta)
end

function Vector3.SmoothDamp(current, target, currentVelocity, smoothTime)
	local maxSpeed = Mathf.Infinity
	local deltaTime = Time.deltaTime smoothTime = max(0.0001, smoothTime) local num = 2 / smoothTime local num2 = num * deltaTime local num3 = 1 / (1 + num2 + 0.48 * num2 * num2 + 0.235 * num2 * num2 * num2) local vector2 = target:Clone() local maxLength = maxSpeed * smoothTime
	local vector = current - target vector:ClampMagnitude(maxLength) target = current - vector local vec3 = (currentVelocity + (vector * num)) * deltaTime currentVelocity = (currentVelocity - (vec3 * num)) * num3 local vector4 = target + (vector + vec3) * num3 if Vector3.Dot(vector2 - current, vector4 - vector2) > 0 then vector4 = vector2 currentVelocity:Set(0,0,0) end return vector4, currentVelocity
end function Vector3.Scale(a, b)
	local x = a.x * b.x
	local y = a.y * b.y
	local z = a.z * b.z
	return _new(x, y, z)
end

function Vector3.Cross(lhs, rhs)
	local x = lhs.y * rhs.z - lhs.z * rhs.y
	local y = lhs.z * rhs.x - lhs.x * rhs.z
	local z = lhs.x * rhs.y - lhs.y * rhs.x
	return _new(x,y,z)
end

function Vector3:Equals(other)
	return self.x == other.x and self.y == other.y and self.z == other.z
end function Vector3.Reflect(inDirection, inNormal)
	local num = -2 * dot(inNormal, inDirection)
	inNormal = inNormal * num
	inNormal:Add(inDirection)
	return inNormal
end function Vector3.Project(vector, onNormal)
	local num = onNormal:SqrMagnitude() if num < 1.175494e-38 then return _new(0,0,0)
	end local num2 = dot(vector, onNormal)
	local v3 = onNormal:Clone()
	v3:Mul(num2/num)
	return v3
end

function Vector3.ProjectOnPlane(vector, planeNormal)
	local v3 = Vector3.Project(vector, planeNormal)
	v3:Mul(-1)
	v3:Add(vector)
	return v3
end function Vector3.Slerp(from, to, t)
	local omega, sinom, scale0, scale1

	if t <= 0 then return from:Clone()
	elseif t >= 1 then return to:Clone()
	end local v2 	= to:Clone()
	local v1 	= from:Clone()
	local len2 	= to:Magnitude()
	local len1 	= from:Magnitude()
	v2:Div(len2)
	v1:Div(len1)

	local len 	= (len2 - len1) * t + len1
	local cosom = v1.x * v2.x + v1.y * v2.y + v1.z * v2.z if cosom > 1 - 1e-6 then
		scale0 = 1 - t
		scale1 = t
	elseif cosom < -1 + 1e-6 then local axis = OrthoNormalVector(from) local q = Quaternion.AngleAxis(180.0 * t, axis) local v = q:MulVec3(from)
		v:Mul(len) return v
	else
		omega 	= acos(cosom)
		sinom 	= sin(omega)
		scale0 	= sin((1 - t) * omega) / sinom
		scale1 	= sin(t * omega) / sinom
	end

	v1:Mul(scale0)
	v2:Mul(scale1)
	v2:Add(v1)
	v2:Mul(len)
	return v2
end


function Vector3:Mul(q)
	if type(q) == "number" then
		self.x = self.x * q
		self.y = self.y * q
		self.z = self.z * q
	else
		self:MulQuat(q)
	end return self
end

function Vector3:Div(d)
	self.x = self.x / d
	self.y = self.y / d
	self.z = self.z / d return self
end

function Vector3:Add(vb)
	self.x = self.x + vb.x
	self.y = self.y + vb.y
	self.z = self.z + vb.z return self
end

function Vector3:Sub(vb)
	self.x = self.x - vb.x
	self.y = self.y - vb.y
	self.z = self.z - vb.z return self
end

function Vector3:MulQuat(quat) local num 	= quat.x * 2
	local num2 	= quat.y * 2
	local num3 	= quat.z * 2
	local num4 	= quat.x * num
	local num5 	= quat.y * num2
	local num6 	= quat.z * num3
	local num7 	= quat.x * num2
	local num8 	= quat.x * num3
	local num9 	= quat.y * num3
	local num10 = quat.w * num
	local num11 = quat.w * num2
	local num12 = quat.w * num3 local x = (((1 - (num5 + num6)) * self.x) + ((num7 - num12) * self.y)) + ((num8 + num11) * self.z)
	local y = (((num7 + num12) * self.x) + ((1 - (num4 + num6)) * self.y)) + ((num9 - num10) * self.z)
	local z = (((num8 - num11) * self.x) + ((num9 + num10) * self.y)) + ((1 - (num4 + num5)) * self.z) self:Set(x, y, z)
	return self
end

function Vector3.AngleAroundAxis (from, to, axis) from = from - Vector3.Project(from, axis)
	to = to - Vector3.Project(to, axis) local angle = Vector3.Angle (from, to) return angle * (Vector3.Dot (axis, Vector3.Cross (from, to)) < 0 and -1 or 1)
end


Vector3.__tostring = function(self)
	return "["..self.x..","..self.y..","..self.z.."]"
end

Vector3.__div = function(va, d)
	return _new(va.x / d, va.y / d, va.z / d)
end

Vector3.__mul = function(va, d)
	if type(d) == "number" then
		return _new(va.x * d, va.y * d, va.z * d)
	else
		local vec = va:Clone()
		vec:MulQuat(d)
		return vec
	end
end

Vector3.__add = function(va, vb)
	return _new(va.x + vb.x, va.y + vb.y, va.z + vb.z)
end

Vector3.__sub = function(va, vb)
	return _new(va.x - vb.x, va.y - vb.y, va.z - vb.z)
end

Vector3.__unm = function(va)
	return _new(-va.x, -va.y, -va.z)
end

Vector3.__eq = function(a,b)
	local v = a - b
	local delta = v:SqrMagnitude()
	return delta < 1e-10
end

get.up 		= function() return _new(0,1,0) end
get.down 	= function() return _new(0,-1,0) end
get.right	= function() return _new(1,0,0) end
get.left	= function() return _new(-1,0,0) end
get.forward = function() return _new(0,0,1) end
get.back	= function() return _new(0,0,-1) end
get.zero	= function() return _new(0,0,0) end
get.one		= function() return _new(1,1,1) end

get.magnitude	= Vector3.Magnitude
get.normalized	= Vector3.Normalize
get.sqrMagnitude= Vector3.SqrMagnitude

UnityEngine.Vector3 = Vector3
setmetatable(Vector3, Vector3)
return Vector3
